GE 469

62 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
CURRENT
DEMAND
1AD0 Current demand period 5 90 1 min F1 15
1AD1 Current demand alarm 0 2 1 -- F115 0
1AD2 Current demand alarm relays 0 6 1 -- F113 0
1AD3 Current demand alarm level 10 100000 1 A F9 100
1AD5 Current demand alarm events 0 1 1 -- F103 0
1AD6 Reserved
1AD7 Reserved
... ...
1ADF Reserved
kW DEMAND 1AE0 kW demand period 5 90 1 min F1 15
1AE1 kW demand alarm 0 2 1 -- F115 0
1AE2 kW demand alarm relays 0 6 1 -- F113 0
1AE3 kW demand alarm level 1 50000 1 kW F1 100
1AE4 kW demand alarm events 0 1 1 -- F103 0
1AE5 Reserved
1AE6 Reserved
... ...
1AEF Reserved
kvar DEMAND 1AF0 kvar demand period 5 90 1 min F1 15
1AF1 kvar demand alarm 0 2 1 -- F115 0
1AF2 kvar demand alarm relays 0 6 1 -- F113 0
1AF3 kvar demand alarm level 1 50000 1 kvar F1 100
1AF4 kvar demand alarm events 0 1 1 -- F103 0
1AF5 Reserved
1AF6 Reserved
... ...
1AFF Reserved
kVA DEMAND 1B00 kVA demand period 5 90 1 min F1 15
1B01 kVA demand alarm 0 2 1 -- F115 0
1B02 kVA demand alarm relays 0 6 1 -- F113 0
1B03 kVA demand alarm level 1 50000 1 kVA F1 100
1B04 kVA demand alarm events 0 1 1 -- F103 0
1B05 Reserved
1B06 Reserved
... ...
1B0F Reserved
PULSE
OUTPUT
1B10 Positive kWh pulse output relay 0 3 1 -- F144 0
1B11 Positive kWh pulse output interval 1 50000 1 kWh F1 1
1B12 Positive kvarh pulse output relay 0 3 1 -- F144 0
1B13 Positive kvarh pulse output interval 1 50000 1 kvarh F1 1
1B14 Negative kvarh pulse output relay 0 3 1 -- F144 0
Table 7: 469 MEMORY MAP (Sheet 44 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
