GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 63
1B15 Negative kvarh pulse output interval 1 50000 1 kvarh F1 1
1B16 Running time pulse relay 0 3 1 -- F144 0
1B17 Running time pulse interval 1 50000 1 s F1 0
1B18 Reserved
1B19 Reserved
... ...
1B1F Reserved
LOSS OF
COMMS
1B20 Loss of Comms Function 0 2 1 -- F115 0 (Off)
1B21 Loss of Comms Function Type 0 1 1 -- F165 0 (Alarm)
1B22 Loss of Comms Port 0 3 1 -- F166
0
(COMP_R
S485)
1B23 Assign Loss of Comms Alarm Relay 0 7 1 -- F113 0 (Alarm)
1B24 Assign Loss of Comms Trip Relay 0 3 1 -- F111 0 (Trip)
1B25 Loss of Comms Delay 1 30 1 s F1 1
1B26 Loss of Comms Alarm Event 0 1 1 -- F103 0 (NO)
1B27 Reserved
,,, ,,,
1B3F Reserved
ANALOG
OUTPUTS
1B40 Analog output 1 selection 0 46 1 -- F127 0
1B41 Analog output 2 selection 0 46 1 -- F127 0
1B42 Analog output 3 selection 0 46 1 -- F127 0
1B43 Analog output 4 selection 0 46 1 -- F127 0
1B44 Phase A current minimum 0 100000 1 A F9 0
1B46 Phase A current maximum 0 100000 1 A F9 100
1B48 Phase B current minimum 0 100000 1 A F9 0
1B4A Phase B current maximum 0 100000 1 A F9 100
1B4C Phase C current minimum 0 100000 1 A F9 0
1B4E Phase C current maximum 0 100000 1 A F9 100
1B50 Average phase current minimum 0 100000 1 A F9 0
1B52 Average phase current maximum 0 100000 1 A F9 100
1B54 AB line voltage minimum 50 20000 1 V F1 3200
1B55 AB line voltage maximum 50 20000 1 V F1 4500
1B56 BC line voltage minimum 50 20000 1 V F1 3200
1B57 BC line voltage maximum 50 20000 1 V F1 4500
1B58 CA line voltage minimum 50 20000 1 V F1 3200
1B59 CA line voltage maximum 50 20000 1 V F1 4500
1B5A Average line voltage minimum 50 20000 1 V F1 3200
1B5B Average line voltage maximum 50 20000 1 V F1 4500
1B5C Phase AN voltage minimum 50 20000 1 V F1 1900
1B5D Phase AN voltage maximum 50 20000 1 V F1 2500
1B5E Phase BN voltage minimum 50 20000 1 V F1 1900
Table 7: 469 MEMORY MAP (Sheet 45 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
