GE 469

64 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
1B5F Phase BN voltage maximum 50 20000 1 V F1 2500
1B60 Phase CN voltage minimum 50 20000 1 V F1 1900
1B61 Phase CN voltage maximum 50 20000 1 V F1 2500
1B62 Average phase voltage minimum 50 20000 1 V F1 1900
1B63 Average phase voltage maximum 50 20000 1 V F1 2500
1B64 Hottest stator RTD minimum –50 250 1 °C F4 0
1B65 Hottest stator RTD maximum –50 250 1 °C F4 200
1B66 Hottest bearing RTD minimum –50 250 1 °C F4 0
1B67 Hottest bearing RTD maximum –50 250 1 °C F4 200
1B68 Hottest ambient RTD minimum –50 250 1 °C F4 –50
1B69 Hottest ambient RTD maximum –50 250 1 °C F4 60
1B6A RTD #1 minimum –50 250 1 °C F4 –50
1B6B RTD #1 maximum –50 250 1 °C F4 250
1B6C RTD #2 minimum –50 250 1 °C F4 –50
1B6D RTD #2 maximum –50 250 1 °C F4 250
1B6E RTD #3 minimum –50 250 1 °C F4 –50
1B6F RTD #3 maximum –50 250 1 °C F4 250
1B70 RTD #4 minimum –50 250 1 °C F4 –50
1B71 RTD #4 maximum –50 250 1 °C F4 250
1B72 RTD #5 minimum –50 250 1 °C F4 –50
1B73 RTD #5 maximum –50 250 1 °C F4 250
1B74 RTD #6 minimum –50 250 1 °C F4 –50
1B75 RTD #6 maximum –50 250 1 °C F4 250
1B76 RTD #7 minimum –50 250 1 °C F4 –50
1B77 RTD #7 maximum –50 250 1 °C F4 250
1B78 RTD #8 minimum –50 250 1 °C F4 –50
1B79 RTD #8 maximum –50 250 1 °C F4 250
1B7A RTD #9 minimum –50 250 1 °C F4 –50
1B7B RTD #9 maximum –50 250 1 °C F4 250
1B7C RTD #10 minimum –50 250 1 °C F4 –50
1B7D RTD #10 maximum –50 250 1 °C F4 250
1B7E RTD #11 minimum –50 250 1 °C F4 –50
1B7F RTD #11 maximum –50 250 1 °C F4 250
1B80 RTD #12 minimum –50 250 1 °C F4 –50
1B81 RTD #12 maximum –50 250 1 °C F4 250
1B82 Power factor minimum –99 100 1 lead/lag F21 0.8 lag
1B83 Power factor maximum –99 100 1 lead/lag F21 0.8 lead
1B84 Reactive power minimum –50000 50000 1 kvar F12 0
1B86 Reactive power maximum –50000 50000 1 kvar F12 750
1B88 Real power minimum –50000 50000 1 kW F12 0
1B8A Real power maximum –50000 50000 1 kW F12 1000
1B8C Apparent power minimum 0 50000 1 kVA F1 0
Table 7: 469 MEMORY MAP (Sheet 46 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
