GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 65
1B8D Apparent power maximum 0 50000 1 kVA F1 1250
1B8E Thermal capacity used minimum 0 100 1 %used F1 0
1B8F Thermal capacity used maximum 0 100 1 %used F1 100
1B90 Relay lockout time minimum 0 500 1 min F1 0
1B91 Relay lockout time maximum 0 500 1 min F1 150
1B92 Current demand minimum 0 100000 1 A F9 0
1B94 Current demand maximum 0 100000 1 A F9 700
1B96 kvar demand minimum 0 50000 1 kvar F1 0
1B97 kvar demand maximum 0 50000 1 kvar F1 1000
1B98 kW demand minimum 0 50000 1 kW F1 0
1B99 kW demand maximum 0 50000 1 kW F1 1250
1B9A kVA demand minimum 0 50000 1 kVA F1 0
1B9B kVA demand maximum 0 50000 1 kVA F1 1500
1B9C Motor load minimum 0 2000 1 × FLA F3 0
1B9D Motor load maximum 0 2000 1 × FLA F3 125
1B9E Analog input 1 minimum –50000 50000 1 -- F12 0
1BA0 Analog input 1 maximum –50000 50000 1 -- F12 50000
1BA2 Analog input 2 minimum –50000 50000 1 -- F12 0
1BA4 Analog input 2 maximum –50000 50000 1 -- F12 50000
1BA6 Analog input 3 minimum –50000 50000 1 -- F12 0
1BA8 Analog input 3 maximum –50000 50000 1 -- F12 50000
1BAA Analog input 4 minimum –50000 50000 1 -- F12 0
1BAC Analog input 4 maximum –50000 50000 1 -- F12 50000
1BAE Tachometer minimum 100 7200 1 RPM F1 3500
1BAF Tachometer maximum 100 7200 1 RPM F1 3700
1BB0 MWh minimum 0
99999999
9
1MWhF1750000
1BB2 MWh maximum 0
99999999
9
1MWhF17100000
1BB4 Reserved
1BB5 Reserved
... ...
1BBF Reserved
1BC0 Torque minimum 0 9999999 1 Nm/ftlb F10 0
1BC2 Torque maximum 0 9999999 1 Nm/ftlb F10 0
1BC4 Reserved
1BC5 Reserved
……
1BD3 Reserved
1BD4 Hottest stator RTD minimum (in °F) –57 482 1 °F F4 32
1BD5 Hottest stator RTD maximum (in °F) –57 482 1 °F F4 392
1BD6 Hottest bearing RTD minimum (in °F) –57 482 1 °F F4 32
1BC7 Hottest bearing RTD maximum (in °F) –57 482 1 °F F4 392
Table 7: 469 MEMORY MAP (Sheet 47 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
