GE 469

66 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
1BD8 Hottest ambient RTD minimum (in °F) –57 482 1 °F F4 –57
1BD9 Hottest ambient RTD maximum (in °F) –57 482 1 °F F4 140
1BDA RTD #1 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BDB RTD #1 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BDC RTD #2 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BDD RTD #2 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BDE RTD #3 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BDF RTD #3 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BE0 RTD #4 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BE1 RTD #4 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BE2 RTD #5 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BE3 RTD #5 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BE4 RTD #6 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BE5 RTD #6 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BE6 RTD #7 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BE7 RTD #7 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BE8 RTD #8 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BE9 RTD #8 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BEA RTD #9 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BEB RTD #9 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BEC RTD #10 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BED RTD #10 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BEE RTD #11 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BEF RTD #11 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BF0 RTD #12 minimum (in Fahrenheit) –57 482 1 °F F4 –57
1BF1 RTD #12 maximum (in Fahrenheit) –57 482 1 °F F4 482
1BF2 Reserved
1BF3 Reserved
... ...
1BF7 Reserved
1BF8 Analog input difference 1-2 minimum –50000 50000 1 -- F12 0
1BFA Analog input difference 1-2 maximum –50000 50000 1 -- F12 100
1BFC Analog input difference 3-4 minimum –50000 50000 1 -- F12 0
1BFE Analog input difference 3-4 maximum –50000 50000 1 -- F12 100
1C00 Reserved
1C01 Reserved
... ...
1C0A Reserved
ANALOG
INPUT 1
1C0B Analog input 1 setup 0 3 1 -- F129 0
1C0C Reserved
1C0D Reserved
1C0E Reserved
Table 7: 469 MEMORY MAP (Sheet 48 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
