GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 67
1C0F Reserved
1C10 Analog input 1 units, characters 1 and 2 0 65535 1 -- F22 ‘Un’
1C11 Analog input 1 units, characters 3 and 4 0 65535 1 -- F22 ‘it’
1C12 Analog input 1 units, characters 5 and 6 0 65535 1 -- F22 ‘ ’
1C13 Analog input 1 minimum –50000 50000 1 -- F12 0
1C15 Analog input 1 maximum –50000 50000 1 -- F12 100
1C17 Block analog input 1 from start 0 5000 1 s F1 0
1C18 Analog input 1 alarm 0 2 1 -- F115 0
1C19 Analog input 1 alarm relays 0 6 1 -- F113 0
1C1A Analog input 1 alarm level –50000 50000 1 -- F12 10
1C1C Analog input 1 alarm pickup 0 1 1 -- F130 0
1C1D Analog input 1 alarm delay 1 3000 1 s F2 1
1C1E Analog input 1 alarm events 0 1 1 -- F103 0
1C1F Analog input 1 trip 0 2 1 -- F115 0
1C20 Analog input 1 trip relays 0 3 1 -- F111 0
1C21 Analog input 1 trip level –50000 50000 1 -- F12 20
1C23 Analog input 1 trip pickup 0 1 1 -- F130 0
1C24 Analog input 1 trip delay 1 3000 1 s F2 1
1C25 Analog input 1 name, characters 1 and 2 0 65535 1 -- F22 ‘An’
1C26 Analog input 1 name, characters 3 and 4 0 65535 1 -- F22 ‘al’
1C27 Analog input 1 name, characters 5 and 6 0 65535 1 -- F22 ‘og’
1C28 Analog input 1 name, characters 7 and 8 0 65535 1 -- F22 ‘ I’
1C29 Analog input 1 name, characters 9 and 10 0 65535 1 -- F22 ‘p1’
1C2A Analog input 1 name, characters 11 and 12 0 65535 1 -- F22 ‘ ’
1C2B Reserved
1C2C Reserved
... ...
1C4A Reserved
ANALOG
INPUT 2
1C4B Analog input 2 setup 0 3 1 -- F129 0
1C4C Reserved
1C4D Reserved
1C4E Reserved
1C4F Reserved
1C50 Analog input 2 units, characters 1 and 2 0 65535 1 -- F22 ‘Un’
15C1 Analog input 2 units, characters 3 and 4 0 65535 1 -- F22 ‘it’
1C52 Analog input 2 units, characters 5 and 6 0 65535 1 -- F22 ‘ ’
1C53 Analog Input 2 minimum –50000 50000 1 -- F12 0
1C55 Analog Input 2 maximum –50000 50000 1 -- F12 100
1C57 Block analog input 2 from start 0 5000 1 s F1 0
1C58 Analog input 2 alarm 0 2 1 -- F115 0
1C59 Analog input 2 alarm relays 0 6 1 -- F113 0
1C5A Analog input 2 alarm level –50000 50000 1 -- F12 10
Table 7: 469 MEMORY MAP (Sheet 49 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
