GE 469

68 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
1C5C Analog input 2 alarm pickup 0 1 1 -- F130 0
1C5D Analog input 2 alarm delay 1 3000 1 s F2 1
1C5E Analog input 2 alarm events 0 1 1 -- F103 0
1C5F Analog input 2 trip 0 2 1 -- F115 0
1C60 Analog input 2 trip relays 0 3 1 -- F111 0
1C61 Analog input 2 trip level –50000 50000 1 -- F12 20
1C63 Analog input 2 trip pickup 0 1 1 -- F130 0
1C64 Analog input 2 trip delay 1 3000 1 s F2 1
1C65 Analog input 2 name, characters 1 and 2 0 65535 1 -- F22 ‘An’
1C66 Analog input 2 name, characters 3 and 4 0 65535 1 -- F22 ‘al’
1C67 Analog input 2 name, characters 5 and 6 0 65535 1 -- F22 ‘og’
1C68 Analog input 2 name, characters 7 and 8 0 65535 1 -- F22 ‘ I’
1C69 Analog input 2 name, characters 9 and 10 0 65535 1 -- F22 ‘p2’
1C6A Analog input 2 name, characters 11 and 12 0 65535 1 -- F22 ‘ ’
1C6B Reserved
1C6C Reserved
... ...
1C8A Reserved
ANALOG
INPUT 3
1C8B Analog input 3 setup 0 3 1 - F129 0
1C8C Reserved
1C8D Reserved
1C8E Reserved
1C8F Reserved
1C90 Analog input 3 units, characters 1 and 2 0 65535 1 -- F22 ‘Un’
1C91 Analog input 3 units, characters 3 and 4 0 65535 1 -- F22 ‘it’
1C92 Analog input 3 units, characters 5 and 6 0 65535 1 -- F22 ‘ ’
1C93 Analog input 3 minimum –50000 50000 1 -- F12 0
1C95 Analog input 3 maximum –50000 50000 1 -- F12 100
1C97 Block analog input 3 from start 0 5000 1 s F1 0
1C98 Analog input 3 alarm 0 2 1 -- F115 0
1C99 Analog input 3 alarm relays 0 6 1 -- F113 0
1C9A Analog input 3 alarm level –50000 50000 1 -- F12 10
1C9C Analog input 3 alarm pickup 0 1 1 -- F130 0
1C9D Analog input 3 alarm delay 1 3000 1 s F2 1
1C9E Analog input 3 alarm events 0 1 1 -- F103 0
1C9F Analog input 3 trip 0 2 1 -- F115 0
1CA0 Analog input 3 trip relays 0 3 1 -- F111 0
1CA1 Analog input 3 trip level –50000 50000 1 -- F12 20
1CA3 Analog input 3 trip pickup 0 1 1 -- F130 0
1CA4 Analog input 3 trip delay 1 3000 1 s F2 1
1CA5 Analog input 3 name, characters 1 and 2 0 65535 1 -- F22 ‘An’
1CA6 Analog input 3 name, characters 3 and 4 0 65535 1 -- F22 ‘al’
Table 7: 469 MEMORY MAP (Sheet 50 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
