1CA8 Analog input 3 name, characters 5 and 6 0 65535 1 -- F22 ‘og’
1CA8 Analog input 3 name, characters 7 and 8 0 65535 1 -- F22 ‘ I’
1CA9 Analog input 3 name, characters 9 and 10 0 65535 1 -- F22 ‘p3’
1CAA Analog input 3 name, characters 11 and 12 0 65535 1 -- F22 ‘ ’
1CAB Reserved
1CAC Reserved
... ...
1CCA Reserved
ANALOG
INPUT 4
1CCB Analog input 4 setup 0 3 1 -- F129 0
1CCC Reserved
1CCD Reserved
1CCE Reserved
1CCF Reserved
1CD0 Analog input 4 units, characters 1 and 2 0 65535 1 -- F22 ‘Un’
1CD1 Analog input 4 units, characters 3 and 4 0 65535 1 -- F22 ‘it’
1CD2 Analog input 4 units, characters 5 and 6 0 65535 1 -- F22 ‘ ’
1CD3 Analog input 4 minimum –50000 50000 1 -- F12 0
1CD5 Analog input 4 maximum –50000 50000 1 -- F12 100
1CD7 Block analog input 4 from start 0 5000 1 s F1 0
1CD8 Analog input 4 alarm 0 2 1 -- F115 0
1CD9 Analog input 4 alarm relays 0 6 1 -- F113 0
1CDA Analog input 4 alarm level –50000 50000 1 -- F12 10
1CDC Analog input 4 alarm pickup 0 1 1 -- F130 0
1CDD Analog input 4 alarm delay 1 3000 1 s F2 1
1CDE Analog input 4 alarm events 0 1 1 -- F103 0
1CDF Analog input 4 trip 0 2 1 -- F115 0
1CE0 Analog input 4 trip relays 0 3 1 -- F111 0
1CE1 Analog input 4 trip level –50000 50000 1 -- F12 20
1CE3 Analog input 4 trip pickup 0 1 1 -- F130 0
1CE4 Analog input 4 trip delay 1 3000 1 s F2 1
1CE5 Analog input 3 name, characters 1 and 2 0 65535 1 -- F22 ‘An’
1CE6 Analog input 3 name, characters 3 and 4 0 65535 1 -- F22 ‘al’
1CE7 Analog input 3 name, characters 5 and 6 0 65535 1 -- F22 ‘og’
1CE8 Analog input 3 name, characters 7 and 8 0 65535 1 -- F22 ‘ I’
1CE9 Analog input 3 name, characters 9 and 10 0 65535 1 -- F22 ‘p4’
1CEA Analog input 3 name, characters 11 and 12 0 65535 1 -- F22 ‘ ’
1CEB Reserved
1CEC Reserved
... ...
1CFF Reserved
Table 7: 469 MEMORY MAP (Sheet 51 of 90)
