GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 71
1D4B Fault analog input 1 0 100 1 %range F1 0
1D4C Fault analog input 2 0 100 1 %range F1 0
1D4D Fault analog input 3 0 100 1 %range F1 0
1D4E Fault analog input 4 0 100 1 %range F1 0
1D4F Fault differential current 0 110 1 × CT F3 0
1D50 Reserved
1D51 Reserved
... ...
1D7B Reserved
1D7C Fault stator RTD temperature (in °F) –58 482 1 °F F4 104
1D7D Fault bearing RTD temperature (in °F) –58 482 1 °F F4 104
1D7E Fault other RTD temperature (in °F) –58 482 1 °F F4 104
1D7F Fault ambient RTD temperature (in °F) –58 482 1 °F F4 104
TEST
OUTPUT
RELAYS
1D80 Force operation of relays 0 8 1 -- F139 0
1D81 Reserved
1D82 Reserved
... ...
1D8F Reserved
TEST
ANALOG
OUTPUTS
1D90 Force analog outputs 0 1 1 -- F126 0
1D91 Analog output 1 forced value 0 100 1 %range F1 0
1D92 Analog output 2 forced value 0 100 1 %range F1 0
1D93 Analog output 3 forced value 0 100 1 %range F1 0
1D94 Analog output 4 forced value 0 100 1 %range F1 0
1D95 Reserved
1D96 Reserved
... ...
1DFE Reserved
SPEED 2
O/L SETUP
1DFF Speed 2 standard overload curve number 1 15 1 -- F1 4
1E00 Speed 2 time to trip at 1.01 x FLA 5 999999 1 s F10 174145
1E02 Speed 2 time to trip at 1.05 x FLA 5 999999 1 s F10 34149
1E04 Speed 2 time to trip at 1.10 x FLA 5 999999 1 s F10 16667
1E06 Speed 2 time to trip at 1.20 x FLA 5 999999 1 s F10 7954
1E08 Speed 2 time to trip at 1.30 x FLA 5 999999 1 s F10 5072
1E0A Speed 2 time to trip at 1.40 x FLA 5 999999 1 s F10 3646
1E0C Speed 2 time to trip at 1.50 x FLA 5 999999 1 s F10 2800
1E0E Speed 2 time to trip at 1.75 x FLA 5 999999 1 s F10 1697
1E10 Speed 2 time to trip at 2.00 x FLA 5 999999 1 s F10 1166
1E12 Speed 2 time to trip at 2.25 x FLA 5 999999 1 s F10 861
1E14 Speed 2 time to trip at 2.50 x FLA 5 999999 1 s F10 666
1E16 Speed 2 time to trip at 2.75 x FLA 5 999999 1 s F10 533
Table 7: 469 MEMORY MAP (Sheet 53 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
