GE 469

72 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
1E18 Speed 2 time to trip at 3.00 x FLA 5 999999 1 s F10 437
1E1A Speed 2 time to trip at 3.25 x FLA 5 999999 1 s F10 366
1E1C Speed 2 time to trip at 3.50 x FLA 5 999999 1 s F10 311
1E1E Speed 2 time to trip at 3.75 x FLA 5 999999 1 s F10 268
1E20 Speed 2 time to trip at 4.00 x FLA 5 999999 1 s F10 233
1E22 Speed 2 time to trip at 4.25 x FLA 5 999999 1 s F10 205
1E24 Speed 2 time to trip at 4.50 x FLA 5 999999 1 s F10 182
1E26 Speed 2 time to trip at 4.75 x FLA 5 999999 1 s F10 162
1E28 Speed 2 time to trip at 5.00 x FLA 5 999999 1 s F10 146
1E2A Speed 2 time to trip at 5.50 x FLA 5 999999 1 s F10 120
1E2C Speed 2 time to trip at 6.00 x FLA 5 999999 1 s F10 100
1E2E Speed 2 time to trip at 6.50 x FLA 5 999999 1 s F10 85
1E30 Speed 2 time to trip at 7.00 x FLA 5 999999 1 s F10 73
1E32 Speed 2 time to trip at 7.50 x FLA 5 999999 1 s F10 63
1E34 Speed 2 time to trip at 8.00 x FLA 5 999999 1 s F10 56
1E36 Speed 2 time to trip at 10.0 x FLA 5 999999 1 s F10 56
1E38 Speed 2 time to trip at 15.0 x FLA 5 999999 1 s F10 56
1E3A Speed 2 time to trip at 20.0 x FLA 5 999999 1 s F10 56
1E3C Reserved
1E3D Reserved
... ...
1E4F Reserved
1E50 Speed 2 minimum allowable line voltage 70 95 1 %Rated F1 80
1E51 Speed 2 stall current at minimum Vline 200 1500 1 × FLA F3 480
1E52 Speed 2 safe stall time at minimum Vline 5 9999 1 s F2 200
1E53 Speed 2 acceleration intersect at min. Vline 200 1500 1 × FLA F3 380
1E54 Speed 2 stall current at 100% Vline 200 1500 1 × FLA F3 600
1E55 Speed 2 safe stall time at 100% Vline 5 9999 1 s F2 100
1E56 Speed 2 acceleration intersect at 100% Vline 200 1500 1 × FLA F3 500
1E57 Reserved
1E58 Reserved
... ...
1E8F Reserved
SPEED 2
UNDER
CURRENT
1E90 Block speed 2 undercurrent from start 0 15000 1 s F1 0
1E91 Speed 2 undercurrent alarm 0 2 1 -- F115 0
1E92 Reserved
1E93 Speed 2 undercurrent alarm pickup 10 95 1 × FLA F3 70
1E94 Speed 2 undercurrent alarm delay 1 60 1 s F1 1
1E95 Speed 2 undercurrent alarm events 0 1 1 -- F103 0
1E96 Speed 2 undercurrent trip 0 2 1 -- F115 0
1E97 Reserved
Table 7: 469 MEMORY MAP (Sheet 54 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
