GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 73
1E98 Speed 2 undercurrent trip pickup 10 99 1 × FLA F3 70
1E99 Speed 2 undercurrent trip delay 1 60 1 s F1 1
1E9A Reserved
1E9B Reserved
... ...
1EAF Reserved
SPEED 2
ACCELERA-
TION
1EB0 Speed 2 acceleration timer from start 10 2500 1 s F2 100
1EB1 Acceleration timer from speed one to two 10 2500 1 s F2 100
1EB2 Speed switch trip speed 2 delay 10 2500 1 s F2 50
1EB3 Speed 2 rated speed 100 7200 1 RPM F1 3600
1EB4 Reserved
1EB5 Reserved
... ...
1EFF Reserved
ANALOG
INPUT 1-2
DIFF.
1F00 Analog In Differential 1-2 Enable 0 1 1 -- F126 0
1F01 1st & 2nd chars. of analog in diff 1-2 name 0 65535 1 -- F22 ‘An’
1F02 3rd & 4th chars. of analog in diff 1-2 name 0 65535 1 -- F22 ‘al’
1F03 5th & 6th chars. of analog in diff 1-2 name 0 65535 1 -- F22 ‘og’
1F04 7th & 8th chars. of analog in diff 1-2 name 0 65535 1 -- F22 ‘ 1’
1F05 9th & 10th chars. of analog in diff 1-2 name 0 65535 1 -- F22 ‘-2’
1F06 11th & 12th char of analog in diff 1-2 name 0 65535 1 -- F22 ‘ ’
1F07 Analog input differential 1-2 comparison 0 1 1 -- F145 0
1F08 Analog input differential 1-2 logic 0 2 1 -- F146 0
1F09 Analog input differential 1-2 active when 0 1 1 -- F147 0
1F0A Analog input differential 1-2 block from start 0 5000 1 s F1 0
1F0B Analog input differential 1-2 alarm 0 2 1 -- F115 0
1F0C Analog input differential 1-2 alarm relays 0 6 1 -- F113 0
1F0D Analog input differential 1-2 percent alarm 0 500 1 % F1 10
1F0E Analog input differential 1-2 absolute alarm 0 50000 1 Units F1 10
1F0F Analog input differential 1-2 alarm delay 1 3000 1 s F2 1
1F10 Analog input differential 1-2 alarm events 0 1 1 -- F103 0
1F11 Analog input differential 1-2 trip 0 2 1 -- F115 0
1F12 Analog input differential 1-2 trip relays 0 6 1 -- F111 0
1F13 Analog input differential 1-2 percent trip 0 500 1 % F1 10
1F14 Analog input differential 1-2 absolute trip 0 50000 1 Units F1 10
1F15 Analog input differential 1-2 trip delay 1 3000 1 s F2 1
1F16 Reserved
1F17 Reserved
... ...
1F1F Reserved
Table 7: 469 MEMORY MAP (Sheet 55 of 90)
