GE 469

74 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
ANALOG
INPUT 3-4
DIFF.
1F20 Analog In Differential 3-4 Enable 0 1 1 -- F126 0
1F21 1st & 2nd chars. of analog in diff 3-4 name 0 65535 1 -- F22 ‘An’
1F21 3rd & 4th chars. of analog in diff 3-4 name 0 65535 1 -- F22 ‘al’
1F21 5th & 6th chars. of analog in diff 3-4 name 0 65535 1 -- F22 ‘og’
1F21 7th & 8th chars. of analog in diff 3-4 name 0 65535 1 -- F22 ‘ 3’
1F21 9th & 10th chars. of analog in diff 3-4 name 0 65535 1 -- F22 ‘-4’
1F26 11th & 12th char of analog in diff 3-4 name 0 65535 1 -- F22 ‘ ’
1F27 Analog input differential 3-4 comparison 0 1 1 -- F145 0
1F28 Analog input differential 3-4 logic 0 2 1 -- F146 0
1F29 Analog input differential 3-4 active when 0 1 1 -- F147 0
1F2A Analog input differential 3-4 block from start 0 5000 1 s F1 0
1F2B Analog input differential 3-4 alarm 0 2 1 -- F115 0
1F2C Analog input differential 3-4 alarm relays 0 6 1 -- F113 0
1F2D Analog input differential 3-4 percent alarm 0 500 1 % F1 10
1F2E Analog input differential 3-4 absolute alarm 0 50000 1 Units F1 10
1F2F Analog input differential 3-4 alarm delay 1 3000 1 s F2 1
1F30 Analog input differential 3-4 alarm events 0 1 1 -- F103 0
1F31 Analog input differential 3-4 trip 0 2 1 -- F115 0
1F32 Analog input differential 3-4 trip relays 0 3 1 -- F111 0
1F33 Analog input differential 3-4 percent trip 0 500 1 % F1 10
1F34 Analog input differential 3-4 absolute trip 0 50000 1 Units F1 10
1F35 Analog input differential 3-4 trip delay 1 3000 1 s F2 1
1F36 Reserved
1F36 Reserved
... ...
2FFF Reserved
Event Recorder / Trace Memory (Addresses 3000 -3FFF)
EVENT
RECORDER
3000 Event recorder last reset (2 words) -- -- -- -- F18 --
3002 Total number of events since last clear 0 65535 1 -- F1 0
3003 Event record select (1=newest, 256=oldest) 1 256 1 -- F1 1
3004 Cause of event 0 143 1 - F134 0
3005 Time of event (2 words) -- -- -- -- F19 --
3007 Date of event (2 words) -- -- -- -- F18 --
3009 Motor speed during event 0 1 1 - F135 0
300A Event tachometer RPM 0 7200 1 RPM F1 0
300B Event phase A current 0 100000 1 A F9 0
300D Event phase B current 0 100000 1 A F9 0
300F Event phase C current 0 100000 1 A F9 0
3011 Event motor load 0 2000 1 FLA F3 0
3012 Event current unbalance 0 100 1 % F1 0
3013 Event ground current 0 5000 1 A F11 0
Table 7: 469 MEMORY MAP (Sheet 56 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
