GE 469

COMMUNICATIONS GUIDE MODBUS MEMORY MAP
469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE 75
3015 Event phase A differential current 0 5000 1 A F1 0
3016 Event phase B differential current 0 5000 1 A F1 0
3017 Event phase C differential current 0 5000 1 A F1 0
3018 Event hottest stator RTD 0 12 1 -- F1 0
3019 Event temperature of hottest stator RTD –50 250 1 °C F4 0
301A Event hottest bearing RTD 0 12 1 -- F1 0
301B Event temperature of hottest bearing RTD –50 250 1 °C F4 0
301C Event hottest other RTD 0 12 1 -- F1 0
301D Event temperature of hottest other RTD –50 250 1 °C F4 0
301E Event hottest ambient RTD 0 12 1 -- F1 0
301F Event ambient RTD temperature –50 250 1 °C F4 0
3020 Event voltage Vab 0 20000 1 V F1 0
3021 Event voltage Vbc 0 20000 1 V F1 0
3022 Event voltage Vca 0 20000 1 V F1 0
3023 Event voltage Van 0 20000 1 V F1 0
3024 Event voltage Vbn 0 20000 1 V F1 0
3025 Event voltage Vcn 0 20000 1 V F1 0
3026 Event system frequency 0 12000 1 Hz F3 0
3027 Event real power –50000 50000 1 kW F12 0
3029 Event reactive power –50000 50000 1 kvar F12 0
302B Event apparent power 0 50000 1 kVA F1 0
302C Event power factor –99 100 1 -- F21 0
302D Event analog input #1 –50000 50000 1 -- F12 0
302F Event analog input #2 –50000 50000 1 -- F12 0
3031 Event analog input #3 –50000 50000 1 -- F12 0
3033 Event analog input #4 –50000 50000 1 -- F12 0
3035 Event torque 0 9999999 1 Nm/ftlb F2 0
3037 Reserved
3038 Reserved
……
30E0 Event temperature of hottest stator RTD (°F) –58 482 1 °F F4 32
30E1 Event temp. of hottest bearing RTD (°F) –58 482 1 °F F4 32
30E2 Event temperature of hottest other RTD (°F) –58 482 1 °F F4 32
30E3 Event ambient RTD temperature (in °F) –58 482 1 °F F4 32
30E4 Reserved
30E5 Reserved
...
30EF Reserved
TRACE
MEMORY
30F0 Trace number selector 1 65535 1 - F1 0
30F1 Trace memory channel selector 0 10 1 - F1 0
30F2 Trace memory date -- -- -- -- F18 --
30F4 Trace memory time -- -- -- -- F19 --
Table 7: 469 MEMORY MAP (Sheet 57 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
