GE 469

76 469 MOTOR MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MODBUS MEMORY MAP COMMUNICATIONS GUIDE
30F6 Trace trigger cause 0 131 1 - F134 --
30F7 Number of samples per trace 1 1536 1 - F1 --
30F8 Number of traces taken 0 65535 1 - F1 --
30F9 Trace memory sampling frequency -- -- 1 Hz F3 --
30FA Trace memory trigger index 1
Number of
samples
per trace
1F1
30FB Reserved
30FC Reserved
30FD Reserved
30FE Reserved
30FF Reserved
3100 Trace memory sample #1 -32767 32767 1 -- F157 0
3101 Trace memory sample #2 -32767 32767 1 -- F157 0
3102 Trace memory sample #3 -32767 32767 1 -- F157 0
3103 Trace memory sample #4 -32767 32767 1 -- F157 0
3104 Trace memory sample #5 -32767 32767 1 -- F157 0
3105 Trace memory sample #6 -32767 32767 1 -- F157 0
3106 Trace memory sample #7 -32767 32767 1 -- F157 0
3107 Trace memory sample #8 -32767 32767 1 -- F157 0
3108 Trace memory sample #9 -32767 32767 1 -- F157 0
3109 Trace memory sample #10 -32767 32767 1 -- F157 0
310A Trace memory sample #11 -32767 32767 1 -- F157 0
310B Trace memory sample #12 -32767 32767 1 -- F157 0
310C Trace memory sample #13 -32767 32767 1 -- F157 0
310D Trace memory sample #14 -32767 32767 1 -- F157 0
310E Trace memory sample #15 -32767 32767 1 -- F157 0
310F Trace memory sample #16 -32767 32767 1 -- F157 0
3110 Trace memory sample #17 -32767 32767 1 -- F157 0
3111 Trace memory sample #18 -32767 32767 1 -- F157 0
3112 Trace memory sample #19 -32767 32767 1 -- F157 0
3113 Trace memory sample #20 -32767 32767 1 -- F157 0
3114 Trace memory sample #21 -32767 32767 1 -- F157 0
3115 Trace memory sample #22 -32767 32767 1 -- F157 0
3116 Trace memory sample #23 -32767 32767 1 -- F157 0
3117 Trace memory sample #24 -32767 32767 1 -- F157 0
3118 Trace memory sample #25 -32767 32767 1 -- F157 0
3119 Trace memory sample #26 -32767 32767 1 -- F157 0
311A Trace memory sample #27 -32767 32767 1 -- F157 0
311B Trace memory sample #28 -32767 32767 1 -- F157 0
311C Trace memory sample #29 -32767 32767 1 -- F157 0
311D Trace memory sample #30 -32767 32767 1 -- F157 0
311E Trace memory sample #31 -32767 32767 1 -- F157 0
311F Trace memory sample #32 -32767 32767 1 -- F157 0
3120 Trace memory sample #33 -32767 32767 1 -- F157 0
3121 Trace memory sample #34 -32767 32767 1 -- F157 0
3122 Trace memory sample #35 -32767 32767 1 -- F157 0
Table 7: 469 MEMORY MAP (Sheet 58 of 90)
GROUP
ADDR
(HEX)
DESCRIPTION MIN. MAX.
STEP
VALUE
UNITS
FORMAT
CODE
DEFAULT
