CHAPTER 6: DNP POINT LISTS ANALOG INPUT / ANALOG INPUT CHANGE
750/760 FEEDER MANAGEMENT RELAY – COMMUNICATIONS GUIDE 6 - 11
160 280 F52 Distance To Fault 8
161 281 F53 Line Z1 To Fault 8 (Magnitude)
162 282 F23 Date Of Fault 9 (Upper 16 Bits - See Note 1)
163 283 F23 Date Of Fault 9 (Lower 16 Bits - See Note 1)
164 284 F22 Time Of Fault 9 (Upper 16 Bits - See Note 1)
165 285 F22 Time Of Fault 9 (Lower 16 Bits - See Note 1)
166 286 F76 Type Of Fault 9
167 287 F52 Distance To Fault 9
168 288 F53 Line Z1 To Fault 9 (Magnitude)
169 289 F49 Reserved for MOD 008 Class 1
170 290 F49 Neutral Displacement Class 1
171 291 F49 Ground Directional is Reverse Class 1
172 292 F49 Reserved For MOD 010 Class 1
173 293 F49 User Input I Class 1
174 294 F49 User Input J Class 1
175 295 F49 User Input K Class 1
176 296 F49 User Input L Class 1
177 297 F49 User Input M Class 1
178 298 F49 User Input N Class 1
179 299 F49 User Input O Class 1
180 300 F49 User Input P Class 1
181 301 F49 User Input Q Class 1
182 302 F49 User Input R Class 1
183 303 F49 User Input S Class 1
184 304 F49 User Input T Class 1
185 305 F49 Autoreclose Rate Supervision Class 1
186 306 F49 Restricted Earth Fault Class 1
187 307 F1 Auto Ranging Power / Energy Multiplier Class 2
188 308 F3 Neutral Voltage (see Note 3) Class 2
Table 3: Analog Inputs DNP Points (Sheet 7 of 8)
Index when Point
Mapping is:
Format Description Event
Class
Assigned
Disable
d
Enabled
