CHAPTER 6: DNP POINT LISTS BINARY / CONTROL RELAY OUTPUT
750/760 FEEDER MANAGEMENT RELAY – COMMUNICATIONS GUIDE 6 - 3
Binary / Control Relay Output
The point list for Binary Output (Object 10) and Control Relay Output (Object 12) is
shown below.
The following restrictions should be observed when using object 12 to control the points
listed in the above table.
Table 2: Binary Outputs DNP Points
Index Description
0Reset
1Open Breaker
2Close Breaker
3 Virtual Input 1
4 Virtual Input 2
5 Virtual Input 3
6 Virtual Input 4
7 Virtual Input 5
8 Virtual Input 6
9 Virtual Input 7
10 Virtual Input 8
11 Virtual Input 9
12 Virtual Input 10
13 Virtual Input 11
14 Virtual Input 12
15 Virtual Input 13
16 Virtual Input 14
17 Virtual Input 15
18 Virtual Input 16
19 Virtual Input 17
20 Virtual Input 18
21 Virtual Input 19
22 Virtual Input 20
23 Breaker Control
