CHAPTER 4: MODBUS MEMORY MAP MEMORY MAP
750/760 FEEDER MANAGEMENT RELAY – COMMUNICATIONS GUIDE 4 - 7
0091 Virtual Input 1 --- --- F66 Not Asserted
0092 Virtual Input 2 --- --- F66 Not Asserted
0093 Virtual Input 3 --- --- F66 Not Asserted
0094 Virtual Input 4 --- --- F66 Not Asserted
0095 Virtual Input 5 --- --- F66 Not Asserted
0096 Virtual Input 6 --- --- F66 Not Asserted
0097 Virtual Input 7 --- --- F66 Not Asserted
0098 Virtual Input 8 --- --- F66 Not Asserted
0099 Virtual Input 9 --- --- F66 Not Asserted
009A Virtual Input 10 --- --- F66 Not Asserted
009B Virtual Input 11 --- --- F66 Not Asserted
009C Virtual Input 12 --- --- F66 Not Asserted
009D Virtual Input 13 --- --- F66 Not Asserted
009E Virtual Input 14 --- --- F66 Not Asserted
009F Virtual Input 15 --- --- F66 Not Asserted
00A0 Virtual Input 16 --- --- F66 Not Asserted
00A1 Virtual Input 17 --- --- F66 Not Asserted
00A2 Virtual Input 18 --- --- F66 Not Asserted
00A3 Virtual Input 19 --- --- F66 Not Asserted
00A4 Virtual Input 20 --- --- F66 Not Asserted
SET TIME AND DATE (read/write)
00F0
1
Set Time (2 words) --- --- F22 ---
00F2
1
Set Date (2 words) --- --- F23 ---
USER MAP VALUES (read only)
0100 User Map Value #1 --- --- --- ---
0101 User Map Value #2 --- --- --- ---
0102 User Map Value #3 --- --- --- ---
0103 User Map Value #4 --- --- --- ---
0104 User Map Value #5 --- --- --- ---
0105 User Map Value #6 --- --- --- ---
0106 User Map Value #7 --- --- --- ---
0107 User Map Value #8 --- --- --- ---
0108 User Map Value #9 --- --- --- ---
0109 User Map Value #10 --- --- --- ---
010A User Map Value #11 --- --- --- ---
010B User Map Value #12 --- --- --- ---
010C User Map Value #13 --- --- --- ---
010D User Map Value #14 --- --- --- ---
010E User Map Value #15 --- --- --- ---
010F User Map Value #16 --- --- --- ---
0110 User Map Value #17 --- --- --- ---
0111 User Map Value #18 --- --- --- ---
0112 User Map Value #19 --- --- --- ---
0113 User Map Value #20 --- --- --- ---
0114 User Map Value #21 --- --- --- ---
0115 User Map Value #22 --- --- --- ---
0116 User Map Value #23 --- --- --- ---
0117 User Map Value #24 --- --- --- ---
0118 User Map Value #25 --- --- --- ---
0119 User Map Value #26 --- --- --- ---
011A User Map Value #27 --- --- --- ---
011B User Map Value #28 --- --- --- ---
Table 3: Modbus Memory Map (Sheet 2 of 40)
ADDR DESCRIPTION RANGE UNITS TYPE DEFAULT
1 2 3 4 5 6 7 8 9 10 11 12 13
For explanation of Table footnotes, see the Memory Map Notes at the end of this table.
