GE 750

CHAPTER 4: MODBUS MEMORY MAP MEMORY MAP
750/760 FEEDER MANAGEMENT RELAY – COMMUNICATIONS GUIDE 4 - 41
1BD3
1
Phase Time Overcurrent 1 Raised Pickup 0 to 100 % F1 0%
1BD4
1
Neutral Time Overcurrent 1 Raised Pickup 0 to 100 % F1 0%
1BD5
1
Ground Time Overcurrent Raised Pickup 0 to 100 % F1 0%
1BD6
1
Negative Sequence Time Overcurrent Raised Pickup 0 to 100 % F1 0%
1BD7
3
Sensitive Ground Time Overcurrent Raised Pickup 0 to 100 % F1 0%
RECLOSURE SHOT 3 (read/write setpoints, 760 only)
1BE0
2
Deadtime Before Reclosure 3 0.00 to 300.00 s F3 4.00 s
1BE1
1
Select Setpoint Group --- --- F80 Active Group
1BE2
2
Overcurrent Blocking Flags --- --- F59 None blocked
1BE3
1
Phase Time Overcurrent 1 Raised Pickup 0 to 100 % F1 0%
1BE4
1
Neutral Time Overcurrent 1 Raised Pickup 0 to 100 % F1 0%
1BE5
1
Ground Time Overcurrent Raised Pickup 0 to 100 % F1 0%
1BE6
1
Negative Sequence Time Overcurrent Raised Pickup 0 to 100 % F1 0%
1BE7
3
Sensitive Ground Time Overcurrent Raised Pickup 0 to 100 % F1 0%
RECLOSURE SHOT 4 (read/write setpoints, 760 only)
1BF0
2
Deadtime Before Reclosure 4 0.00 to 300.00 s F3 5.00 s
1BF1
1
Select Setpoint Group --- --- F80 Active Group
1BF2
2
Overcurrent Blocking Flags --- --- F59 None blocked
1BF3
1
Phase Time Overcurrent 1 Raised Pickup 0 to 100 % F1 0%
1BF4
1
Neutral Time Overcurrent 1 Raised Pickup 0 to 100 % F1 0%
1BF5
1
Ground Time Overcurrent Raised Pickup 0 to 100 % F1 0%
1BF6
1
Negative Sequence Time Overcurrent Raised Pickup 0 to 100 % F1 0%
1BF7
3
Sensitive Ground Time Overcurrent Raised Pickup 0 to 100 % F1 0%
LOGIC INPUT NAMES (read/write setpoints)
1C00
1
Logic Input 1 Name (9 words = 18 characters) --- --- F33 Logic Input 1
1C09
1
Logic Input 2 Name (9 words = 18 characters) --- --- F33 Logic Input 2
1C12
1
Logic Input 3 Name (9 words = 18 characters) --- --- F33 Logic Input 3
1C1B
1
Logic Input 4 Name (9 words = 18 characters) --- --- F33 Logic Input 4
1C24
1
Logic Input 5 Name (9 words = 18 characters) --- --- F33 Logic Input 5
1C2D
1
Logic Input 6 Name (9 words = 18 characters) --- --- F33 Logic Input 6
1C36
1
Logic Input 7 Name (9 words = 18 characters) --- --- F33 Logic Input 7
1C3F
1
Logic Input 8 Name (9 words = 18 characters) --- --- F33 Logic Input 8
1C48
1
Logic Input 9 Name (9 words = 18 characters) --- --- F33 Logic Input 9
1C51
1
Logic Input 10 Name (9 words = 18 characters) --- --- F33 Logic Input 10
1C5A
1
Logic Input 11 Name (9 words = 18 characters) --- --- F33 Logic Input 11
1C63
1
Logic Input 12 Name (9 words = 18 characters) --- --- F33 Logic Input 12
1C6C
1
Logic Input 13 Name (9 words = 18 characters) --- --- F33 Logic Input 13
1C75
1
Logic Input 14 Name (9 words = 18 characters) --- --- F33 Logic Input 14
1C7E
1
Logic Input 15 Name (9 words = 18 characters) --- --- F33 Logic Input 15
1C87
1
Logic Input 16 Name (9 words = 18 characters) --- --- F33 Logic Input 16
1C90
1
Logic Input 17 Name (9 words = 18 characters) --- --- F33 Logic Input 17
1C99
1
Logic Input 18 Name (9 words = 18 characters) --- --- F33 Logic Input 18
1CA2
1
Logic Input 19 Name (9 words = 18 characters) --- --- F33 Logic Input 19
1CAB
1
Logic Input 20 Name (9 words = 18 characters) --- --- F33 Logic Input 20
EVENT RECORD SELECTOR (read/write actual values)
2000 Event Number Selector 0 to 65535 --- F1 0
Table 3: Modbus Memory Map (Sheet 36 of 40)
ADDR DESCRIPTION RANGE UNITS TYPE DEFAULT
1 2 3 4 5 6 7 8 9 10 11 12 13
For explanation of Table footnotes, see the Memory Map Notes at the end of this table.
