4 - 44 750/760 FEEDER MANAGEMENT RELAY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 4: MODBUS MEMORY MAP
215D Trace Memory Sample TMSS+61 --- --- F25 ---
215E Trace Memory Sample TMSS+62 --- --- F25 ---
215F Trace Memory Sample TMSS+63 --- --- F25 ---
DATA LOGGER SELECTORS (read/write)
2200 Data Log Number Selector 0 to 65535 --- F1 0
2201 Data Log Channel Selector 0 to 7 --- F1 0
2202 Data Log Sample Selector (DLSS) 0 to 4095 --- F1 0
DATA LOGGER INFORMATION (read only)
2210 Number of Data Log Triggers Since Clear 0 to 65535 --- F1 ---
2211 Number of Data Log Samples Stored 0 to 4096 --- F1 ---
2212 Data Log Start Index 0 to 4095 --- F1 ---
2213 Data Log Trigger Index 0 to 4095 --- F1 ---
2214 Data Log Trigger Cause --- --- F24 ---
2215 Data Log Trigger Date --- --- F23 ---
2217 Data Log Trigger Time --- --- F22 ---
DATA LOGGER SAMPLES (read only)
2220 Data Logger Sample DLSS+0 --- --- F25 ---
2222 Data Logger Sample DLSS+1 --- --- F25 ---
2222 Data Logger Sample DLSS+2 --- --- F25 ---
2223 Data Logger Sample DLSS+3 --- --- F25 ---
2224 Data Logger Sample DLSS+4 --- --- F25 ---
2225 Data Logger Sample DLSS+5 --- --- F25 ---
2226 Data Logger Sample DLSS+6 --- --- F25 ---
2227 Data Logger Sample DLSS+7 --- --- F25 ---
2228 Data Logger Sample DLSS+8 --- --- F25 ---
2229 Data Logger Sample DLSS+9 --- --- F25 ---
222A Data Logger Sample DLSS+10 --- --- F25 ---
222B Data Logger Sample DLSS+11 --- --- F25 ---
222C Data Logger Sample DLSS+12 --- --- F25 ---
222D Data Logger Sample DLSS+13 --- --- F25 ---
222E Data Logger Sample DLSS+14 --- --- F25 ---
222F Data Logger Sample DLSS+15 --- --- F25 ---
2230 Data Logger Sample DLSS+16 --- --- F25 ---
2231 Data Logger Sample DLSS+17 --- --- F25 ---
2232 Data Logger Sample DLSS+18 --- --- F25 ---
2233 Data Logger Sample DLSS+19 --- --- F25 ---
2234 Data Logger Sample DLSS+20 --- --- F25 ---
2235 Data Logger Sample DLSS+21 --- --- F25 ---
2236 Data Logger Sample DLSS+22 --- --- F25 ---
2237 Data Logger Sample DLSS+23 --- --- F25 ---
2238 Data Logger Sample DLSS+24 --- --- F25 ---
2239 Data Logger Sample DLSS+25 --- --- F25 ---
223A Data Logger Sample DLSS+26 --- --- F25 ---
223B Data Logger Sample DLSS+27 --- --- F25 ---
223C Data Logger Sample DLSS+28 --- --- F25 ---
223D Data Logger Sample DLSS+29 --- --- F25 ---
223E Data Logger Sample DLSS+30 --- --- F25 ---
223F Data Logger Sample DLSS+31 --- --- F25 ---
2240 Data Logger Sample DLSS+32 --- --- F25 ---
2241 Data Logger Sample DLSS+33 --- --- F25 ---
2242 Data Logger Sample DLSS+34 --- --- F25 ---
2243 Data Logger Sample DLSS+35 --- --- F25 ---
2244 Data Logger Sample DLSS+36 --- --- F25 ---
Table 3: Modbus Memory Map (Sheet 39 of 40)
ADDR DESCRIPTION RANGE UNITS TYPE DEFAULT
1 2 3 4 5 6 7 8 9 10 11 12 13
For explanation of Table footnotes, see the Memory Map Notes at the end of this table.
