CHAPTER 6: DNP POINT LISTS ANALOG INPUT / ANALOG INPUT CHANGE
750/760 FEEDER MANAGEMENT RELAY – COMMUNICATIONS GUIDE 6 - 9
102 222 F22 Time Of Fault 0 (Lower 16 Bits - See Note 1) Class 3
103 223 F76 Type Of Fault 0 Class 3
104 224 F52 Distance To Fault 0 Class 3
105 225 F53 Line Z1 To Fault 0 (Magnitude) Class 3
106 226 F23 Date Of Fault 1 (Upper 16 Bits - See Note 1)
107 227 F23 Date Of Fault 1 (Lower 16 Bits - See Note 1)
108 228 F22 Time Of Fault 1 (Upper 16 Bits - See Note 1)
109 229 F22 Time Of Fault 1 (Lower 16 Bits - See Note 1)
110 230 F76 Type Of Fault 1
111 231 F52 Distance To Fault 1
112 232 F53 Line Z1 To Fault 1 (Magnitude)
113 233 F23 Date Of Fault 2 (Upper 16 Bits - See Note 1)
114 234 F23 Date Of Fault 2 (Lower 16 Bits - See Note 1)
115 235 F22 Time Of Fault 2 (Upper 16 Bits - See Note 1)
116 236 F22 Time Of Fault 2 (Lower 16 Bits - See Note 1)
117 237 F76 Type Of Fault 2
118 238 F52 Distance To Fault 2
119 239 F53 Line Z1 To Fault 2 (Magnitude)
120 240 F23 Date Of Fault 3 (Upper 16 Bits - See Note 1)
121 241 F23 Date Of Fault 3 (Lower 16 Bits - See Note 1)
122 242 F22 Time Of Fault 3 (Upper 16 Bits - See Note 1)
123 243 F22 Time Of Fault 3 (Lower 16 Bits - See Note 1)
124 244 F76 Type Of Fault 3
125 245 F52 Distance To Fault 3
126 246 F53 Line Z1 To Fault 3 (Magnitude)
127 247 F23 Date Of Fault 4 (Upper 16 Bits - See Note 1)
128 248 F23 Date Of Fault 4 (Lower 16 Bits - See Note 1)
129 249 F22 Time Of Fault 4 (Upper 16 Bits - See Note 1)
130 250 F22 Time Of Fault 4 (Lower 16 Bits - See Note 1)
Table 3: Analog Inputs DNP Points (Sheet 5 of 8)
Index when Point
Mapping is:
Format Description Event
Class
Assigned
Disable
d
Enabled
