GE 869 - Page 603

CHAPTER B: APPENDIX B REVISION HISTORY
869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL B–3
4 Added new Pole Discordance section to Setpoints > Control
4 Added new CT Supervision section to Setpoints > Control
4
Added new Contactor Control section to Setpoints > Control > Contactor
Control
4 Added new Ethernet Loopback test section to Setpoints > Testing
4
Created new Contactor logic diagram 894206A1.cdr and revised the
Contactor section in Setpoints > System > Motor > Setup > Switching Device
6
Added new Bearing, Mechanical and Stator fault section to Metering >
Motor
Table 3: Major Updates for 869-A7
PAGE
NUMBER
(A6
PAGE
NUMBER
(A7)
CHANGES
Manual revision number from A6 to A7, and Product version
revision from 1.6x to 1.7x
1-7 1-8 Revised 869 Order Code information
1-21 1-21
Changed Time Delay to 200,000,000 ms for
Introduction>Specifications>User-Programmable
Elements>FlexCurves
2-9 210-
Replaced Typical Wiring diagram (892824A3.cdr) with new
Typical Wiring diagram 892769A1.pdf
4-, 5-, 6-,
7-
4-, 5-, 6-,
7-
Removed the HMIs associated with the path descriptions in
each chapter
- 4-7 Added new Custom Configuration section to Setpoints>Device
- 4-44
Added new Remote Modbus Device section to the
Setpoints>Communications
4-34 4-31
Replaced single communications card option with two
communications card options for "S" and "C" in Setpoints >
Device > Communications > Ethernet Ports
- 4-61
Updated Setpoints>Device>Installation to add Voltage Cutoff
and Current Cutoff settings
4-143 4-133
Revised the Current unbalance section to include the inverse
curves
- 4-144
Added new Loss of Excitation to section
Setpoints>Protection>Motor
4-163 4-167
Removed the "Time" setting from the "Speed2 Acceleration"
element found under Protection>Motor section
4-163 4-159
Removed the "Time" setting from the "Acceleration Time"
element found under Protection>Motor section
- 4-283
Revised Power Factor feature for lead/lag in
Setpoints>Monitoring>Functions
- 4-236
Added new Volts per Hertz section to
Setpoints>Protection>Voltage Elements
- 4-65
Added the "Max. Acceleration Time" and "Speed2 Max. Accel.
Time" settings to the System>Motor>Setup section
Table 2: Major Updates for 869-A8
Chapter CHANGES
