B–4 869 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL
REVISION HISTORY CHAPTER B: APPENDIX B
- 4-233
Added new Out-of-Step section to
Setpoints>Protection>Impedance Elements
- 4-317 Added new RTD Trouble section to Setpoints>Monitoring
- 4-319
Added new Loss of Communications section to
Setpoints>Monitoring
- 4-306 Added new Speed section to Setpoints>Monitoring
4-352 4-352 Updated the FlexLogic Operands table
Table 4: Major Updates for 869-A6
PAGE
NUMBER
(A5)
PAGE
NUMBER
(A6)
CHANGES
cover cover
Manual revision number from A5 to A6, and Product version
revision from 1.5x to 1.6x
cover cover Replaced GE Digital Energy with GE Grid Solutions throughout
1-18 1-17
Added Harmonic detection specification to
Specifications>Monitoring
2-9 2-8
Revised the typical wiring diagram to 892824A3.cdr (renamed
the analog output examples)
- 4-63 Added Configurable Snapshots section to Setpoints>Device
- 4-231
Added Auxiliary Undervoltage to Setpoints>Protection>Voltage
Elements
- 4-283 Added Stator Inter-Turn Fault to Setpoints>Monitoring
- 4-310 Added Harmonic Detection section to Setpoints>Monitoring
4-350 4-315
Moved RTD Temperature from Setpoints>RTD Temperature to
Setpoints>Monitoring>RTD Temperature
4-329 4-342
Revised the FlexLogic table to add Flexlogic operands for
harmonic detection
4-355 4-365 Added Testing>Simulation section after FlexLogic section
- 5-4 Updated the Status chapter to include Last trip data section
- 6-6 Added Stator Inter-Turn Fault to Metering>Motor
6-9 6-10
Replaced "Harmonics 1" and "Harmonics 2" sections with
"Harmonic 1 (Harmonics) 2"
6-12 6-14 "Current J1" renamed "Current 1"
- 6-18 Added FlexElements to Metering chapter
- 7-2 Added Fault Reports to Records chapter
7-4 - Removed Learned Data Records from Records chapter
7-7 7-6 "Motor Learned Data" renamed "Learned Data"
Table 3: Major Updates for 869-A7
PAGE
NUMBER
(A6
PAGE
NUMBER
(A7)
CHANGES
