15
Service Manual
Technical Information
4. Refrigerant System Diagram
HOT DISCHARGED AI
R
OUTDOOR COILS
AXIAL FAN
COMPRESSOR
REFRIGERANT FLOW DIRECTION
CAPILLARY
CENTRIFUGAL
OR CROSS FAN
INDOOR COILS
COOLED AIR
