Your AF-600 FP NON Bypass & Disconnect Drive Panels comes with an AF-600 FP Adjustable Frequency Drive
from GE Drives mounted on or in an enclosure, which contains the following equipment to control motor
operation from the drive.
ABB
Non-Fused Disconnect w/through-the-door lockable handle (or equivalent)
ABB
Fused Disconnect w/through-the-door lockable handle (optional) (or equivalent)
Ferraz Shawmut Fused Disconnect w/through-the-door lockable handle (optional) (or equivalent)
GE Spectra RMS
TM
Mag-Break Solid State Circuit Breaker w/through-the-door lockable handle
GE C-2000
TM
3-Pole Non-Reversing Contactors (optional)
GE C-2000
TM
Class 20/30 Fixed Heater Motor Overload Relays (optional)
GE C-2000
TM
Selector Switches and Pilot Lights
GE Type IP Encapsulated or Vacuum Impregnated 115 VAC Control Power Transformer w/fuses
Busman/ Ferraz Shawmut Amp-trap
Time-Delay Class J Fuses (or equivalent)
GE Line Reactors (optional)
GE Load Reactors (optional)
GE DC Link Reactors (Drive inbuilt)
MTE Line or Load reactor
These instructions are intended as a supplement to the User’s Guide for the AF-600 FP drive. For
programming, operating and troubleshooting instructions for the adjustable frequency drive please refer to
this instruction manual, which is included with your panel documentation package.
DET - 609 AF 600 FP User’s Guide for up to 60HP @ 208V @ & up to 125HP @460/575
DET - 610 AF 600 FP User’s Guide for 150HP and above @ 460/575V
Also included with your panel documentation package are installation instructions, electrical and mechanical
drawings of your panel, and a parts list that includes recommend spares.
DEH40608 – Page 1 AN 11-2021 Rev 05, 12/15/2011
OPERATING AND TROUBLESHOOTING INSTRUCTIONS FOR
AF-600 FP NON BYPASS & DISCONNECT DRIVE PANELS
