P/N 3001324 Rev. H MR11

*Not shown on drawing.

Qty. Code

Part

No. Description Qty.

1244651 Valve Assembly w/o Flow Controls 1 16 Plumbing Adapter Kits: 1

2 1235338* Top Plate, AvantaPure Series Valves 1 1001606 3/4-inch Copper Tube Adapter Kit

3 1235339 Valve Disc Spring, One Piece, Performa 1 1001670 1-inch Copper Tube Adapter Kit

Valve 1001608 22-mm Copper Tube Adapter Kit

4 1242282 Cover, Valve,AvantaPure Controller 1 1001613 3/4-inch CPVC Tube Adapter Kit

5 1235352* Cam, 263-268 AvantaPure Valve, STD, 1 1001614 1-inch CPVC Tube Adapter Kit

Black 1001615 25-mm CPVC Tube Adapter Kit

6 Drain Control Assembly: 1 1001769 3/4-inch NPT Plastic Pipe Adapter Kit

1000212 No. 10 (2.5 gpm; 9.5 Lpm) 1001603 1-inch NPT Plastic Pipe Adapter Kit

1000213 No. 12 (3.5 gpm; 13.2 Lpm) 1001604 3/4-inch BSPT Plastic Pipe Adapter Kit

1000214 No. 13 (4.1 gpm; 15.5 Lpm) 1001605 1-inch BSPT Plastic Pipe Adapter Kit

1000215 No. 14 (4.8 gpm; 18.2 Lpm) 1001611 3/4-inch BSPT Brass Pipe Adapter Kit

7 1235361 Motor/Optical Cable Assembly 1 1001610 1-inch NPT Brass Pipe Adapter Kit

8 1000226 Screen/Cap Assembly w/ O-Ring 1 1001612 1-inch BSPT Brass Pipe Adapter Kit

9 Injector (High Efficiency) Options: 17 1235373 Module, Sensor, Photo Interrupter 1

1035733 “H” Injector (High Efficiency) - Lt Purple 18 1001986 13/16 inch Rubber Insert (Optional) 1

(9-inch tank) 19 1235446 Turbine Cable 1

1035734 “J” Injector (High Efficiency) - Lt Blue 20 1010154 Tank O-Ring 1

(10-inch tank) 21 1000811 AC Adapter, North American 1

1030413 “K” Injector (High Efficiency) - Pink 22 1238362 AvantaPure controller 1

(12-inch tank) (unprogrammed)

1035736 “L” Injector (High Efficiency) - Orange * 1033444 Turbine Assembly

(13 & 14-inch tank) * 1239979 Cable Harness, Remote Regen 740F

1032978 Plugged Injector for 263 Filter * 1239711 Switch Kit, Front Mount, 0.1 amp

1032985 Plugged Injector Cap * 1239752 Switch Kit, Front Mount, 5 amp

10A 1000222 Regenerant Refill Controller, No Ball 1 * 1239753 Switch Kit, Top Plate Mount, 0.1 amp

10B 1243510 Regenerant Refill Controller * 1239754 Switch Kit, Top Plate Mount, 5 amp

11 1030502 Ball, Refill Flow Control * 1242286 Valve Skirt

12 1002449 Drain Fitting Elbow (3/4-inch hose 1 * 1242287 Cover with Shield

barbed) * 1033444 Internal Turbine Meter

13 1010428 O-Ring 1 * 1233187 Motor Locking Pin

14 1000269 Injector Cap with O-Ring 1 * 3001760 Chlorine Generator Kit

15 1035622 Tank Ring 1 * 1239760 Blending Valve Kit

* Drain Line Flow Control 1

1030355 Drain Line Flow Control, 5 gpm (19 Lpm)

1030356 Drain Line Flow Control, 6 gpm (22.5 Lpm)

1030357 Drain Line Flow Control, 7 gpm (26.5 Lpm)

1030358 Drain Line Flow Control, 8 gpm (30 Lpm)

1030359 Drain Line Flow Control, 9 gpm (34 Lpm)

1030360 Drain Line Flow Control, 10 gpm (38 Lpm)

* 1030334 Plugged Refill Flow Control - for 263

Valve

* 1041174 Valve Disc Kit
