2-82 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 6179 July Average Ambient Temperature -60 to 60 °C 1 F002 30
" 617A August Average Ambient Temperature -60 to 60 °C 1 F002 30
" 617B September Average Ambient Temperature -60 to 60 °C 1 F002 20
" 617C October Average Ambient Temperature -60 to 60 °C 1 F002 10
" 617D November Average Ambient Temperature -60 to 60 °C 1 F002 10
" 617E December Average Ambient Temperature -60 to 60 °C 1 F002 -10
Transformer Thermal Inputs (Read/Write Command)
G30, T35, T60 6180 Transformer Loss of Life Clear Command 0 to 1 --- 1 F126 0 (No)
Transformer Percent Differential (Read/Write Grouped Setting)
G30, T35, T60 61C0 Percent Differential Function 0 to 1 --- 1 F102 0 (Disabled)
" 61C1 Percent Differential Pickup 0.05 to 1 pu 0.001 F001 100
" 61C2 Percent Differential Slope 1 15 to 100 % 1 F001 25
" 61C3 Percent Differential Break 1 1 to 2 pu 0.001 F001 2000
" 61C4 Percent Differential Break 2 2 to 30 pu 0.001 F001 8000
" 61C5 Percent Differential Slope 2 50 to 100 % 1 F001 90
" 61C6 Inrush Inhibit Function 0 to 2 --- 1 F168 1 (Adapt.
2nd)
" 61C7 Inrush Inhibit Level 1 to 40 %f
o
0.1 F001 200
" 61C8 Overexcitation Inhibit Function 0 to 1 --- 1 F169 0 (Disabled)
" 61C9 Overexcitation Inhibit Level 1 to 40 %f
o
0.1 F001 100
" 61CA Percent Differential Block 0 to 4294967295 --- 1 F300 0
" 61CC Percent Differential Target 0 to 2 --- 1 F109 0 (Self-reset)
" 61CD Percent Differential Events 0 to 1 --- 1 F102 0 (Disabled)
" 61CE Transformer Inrush Inhibit Mode 0 to 3 --- 1 F189 0 (Per phase)
Transformer Instantaneous Differential (Read/Write Grouped Setting)
T35, T60 61DA Inst Differential Function 0 to 1 --- 1 F102 0 (Disabled)
" 61DB Inst Differential Pickup 2 to 30 pu 0.001 F001 8000
" 61DC Inst Differential Block 0 to 4294967295 --- 1 F300 0
" 61DE Inst Differential Target 0 to 2 --- 1 F109 0 (Self-reset)
" 61DF Inst Differential Events 0 to 1 --- 1 F102 0 (Disabled)
Autoreclose (Read/Write Setting) (1, 3, 4, or 6 Modules)
D30, F35, F60,
L30
6200 Autoreclose 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 6201 Autoreclose 1 Initiate 0 to 4294967295 --- 1 F300 0
" 6203 Autoreclose 1 Block 0 to 4294967295 --- 1 F300 0
" 6205 Autoreclose 1 Max Number of Shots 1 to 4 --- 1 F001 1
" 6206 Autoreclose 1 Manual Close 0 to 4294967295 --- 1 F300 0
" 6208 Autoreclose 1 Manual Reset from LO 0 to 4294967295 --- 1 F300 0
" 620A Autoreclose 1 Reset Lockout if Breaker
Closed
0 to 1 --- 1 F108 0 (Off)
" 620B Autoreclose 1 Reset Lockout On Manual
Close
0 to 1 --- 1 F108 0 (Off)
" 620C Autoreclose 1 Breaker Closed 0 to 4294967295 --- 1 F300 0
" 620E Autoreclose 1 Breaker Open 0 to 4294967295 --- 1 F300 0
" 6210 Autoreclose 1 Block Time Upon Manual
Close
0 to 655.35 s 0.01 F001 1000
" 6211 Autoreclose 1 Dead Time Shot 1 0 to 655.35 s 0.01 F001 100
" 6212 Autoreclose 1 Dead Time Shot 2 0 to 655.35 s 0.01 F001 200
Products Address Register name Range Units Step Format Default
