CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-87
2
" 65A2 CT Trouble 1 Delay 1 to 60 s 0.1 F001 100
" 65A3 CT Trouble 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 65A4 CT Trouble 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 65A5 ...Repeated for CT Trouble 2
B90 65AA ...Repeated for CT Trouble 3
" 65AF ...Repeated for CT Trouble 4
" 65B4 ...Repeated for CT Trouble 5
" 65B9 ...Repeated for CT Trouble 6
Bus Configuration (Read/Write Setting) (6 Modules)
B90 65BE Bus Zone x CT (24 items) 0 to 23 --- 1 F400 0
Power Swing Detect (Read/Write Grouped Setting)
D30, D60, G60,
L60, L90, N60,
T60
65C0 Power Swing Detect Function 0 to 1 --- 1 F102 0 (Disabled)
" 65C1 Power Swing Detect Source 0 to 5 --- 1 F167 0 (SRC 1)
" 65C2 Power Swing Detect Mode 0 to 1 --- 1 F513 0 (Two Step)
" 65C3 Power Swing Detect Supervision 0.05 to 30 pu 0.001 F001 600
" 65C4 Power Swing Detect Forward Reach 0.1 to 500 ohms 0.01 F001 5000
" 65C5 Power Swing Detect Forward RCA 40 to 90 degrees 1 F001 75
" 65C6 Power Swing Detect Reverse Reach 0.1 to 500 ohms 0.01 F001 5000
" 65C7 Power Swing Detect Reverse RCA 40 to 90 degrees 1 F001 75
" 65C8 Power Swing Detect Outer Limit Angle 40 to 140 degrees 1 F001 120
" 65C9 Power Swing Detect Middle Limit Angle 40 to 140 degrees 1 F001 90
" 65CA Power Swing Detect Inner Limit Angle 40 to 140 degrees 1 F001 60
" 65CB Power Swing Detect Delay 1 Pickup 0 to 65.535 s 0.001 F001 30
" 65CC Power Swing Detect Delay 1 Reset 0 to 65.535 s 0.001 F001 50
" 65CD Power Swing Detect Delay 2 Pickup 0 to 65.535 s 0.001 F001 17
" 65CE Power Swing Detect Delay 3 Pickup 0 to 65.535 s 0.001 F001 9
" 65CF Power Swing Detect Delay 4 Pickup 0 to 65.535 s 0.001 F001 17
" 65D0 Power Swing Detect Seal In Delay 0 to 65.535 s 0.001 F001 400
" 65D1 Power Swing Detect Trip Mode 0 to 1 --- 1 F514 0 (Delayed)
" 65D2 Power Swing Detect Block 0 to 4294967295 --- 1 F300 0
" 65D4 Power Swing Detect Target 0 to 2 --- 1 F109 0 (Self-reset)
" 65D5 Power Swing Detect Event 0 to 1 --- 1 F102 0 (Disabled)
" 65D6 Power Swing Detect Shape 0 to 1 --- 1 F085 0 (Mho
Shape)
Bus Configuration (Read/Write Setting) (6 Modules)
B90 65D6 Bus Zone x Dir (24 items) 0 to 1 --- 1 F210 0 (IN)
Power Swing Detect (Read/Write Grouped Setting)
D30, D60, G60,
L60, L90, N60,
T60
65D7 Power Swing Detect Quad Forward Middle 0.1 to 500 ohms 0.01 F001 6000
" 65D8 Power Swing Detect Quad Forward Outer 0.1 to 500 ohms 0.01 F001 7000
" 65D9 Power Swing Detect Quad Reverse Middle 0.1 to 500 ohms 0.01 F001 6000
" 65DA Power Swing Detect Quad Reverse Outer 0.1 to 500 ohms 0.01 F001 7000
" 65DB Power Swing Detect Outer Right Blinder 0.1 to 500 ohms 0.01 F001 10000
" 65DC Power Swing Detect Outer Left Blinder 0.1 to 500 ohms 0.01 F001 10000
" 65DD Power Swing Detect Middle Right Blinder 0.1 to 500 ohms 0.01 F001 10000
Products Address Register name Range Units Step Format Default
