GE b30 Communications Guide

2-110 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
B30, C60, C70,
D30, D60, F35,
F60, G30, G60,
L30, L60, L90,
M60, T35, T60
7300 Breaker 1 Arcing Amp Function 0 to 1 --- 1 F102 0 (Disabled)
" 7301 Breaker 1 Arcing Amp Source 0 to 5 --- 1 F167 0 (SRC 1)
" 7302 Breaker 1 Arcing Amp Init 0 to 4294967295 --- 1 F300 0
" 7304 Breaker 1 Arcing Amp Init B 0 to 4294967295 --- 1 F300 0
" 7306 Breaker 1 Arcing Amp Init C 0 to 4294967295 --- 1 F300 0
" 7308 Breaker 1 Arcing Amp Delay 0 to 65.535 s 0.001 F001 0
" 7309 Breaker 1 Arcing Amp Limit 0 to 50000 kA2-cyc 1 F001 1000
" 730A Breaker 1 Arcing Interruption Rating 0 to 100 kA 0.1 F001 315
" 730B Breaker 1 Arcing Clear Arcing Amps 0 to 4294967295 --- 1 F300 0
" 730D Breaker 1 Arcing Amp Block 0 to 4294967295 --- 1 F300 0
" 730F Breaker 1 Arcing Amp Target 0 to 2 --- 1 F109 0 (Self-reset)
" 7310 Breaker 1 Arcing Amp Events 0 to 1 --- 1 F102 0 (Disabled)
" 7311 ...Repeated for Breaker 2 Arcing Amp
B30, C60, C70,
F35, F60, L90,
T35, T60
7322 ...Repeated for Breaker 3 Arcing Amp
B30, C60, F35,
F60, L90, T35,
T60
7333 ...Repeated for Breaker 4 Arcing Amp
B30, F35, T35,
T60
7344 ...Repeated for Breaker 5 Arcing Amp
" 7355 ...Repeated for Breaker 6 Arcing Amp
Disconnect (Breaker) Switch (Read/Write Setting) (8, 12, 16, or 24 Modules)
All except B90 7370 Disconnect Switch 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 7371 Disconnect Switch 1 Name --- --- --- F206 "SW-1"
" 7374 Disconnect Switch 1 Mode 0 to 1 --- 1 F157 0 (3-Pole)
" 7375 Disconnect Switch 1 Open 0 to 4294967295 --- 1 F300 0
" 7377 Disconnect Switch 1 Block Open 0 to 4294967295 --- 1 F300 0
" 7379 Disconnect Switch 1 Close 0 to 4294967295 --- 1 F300 0
" 737B Disconnect Switch 1 Block Close 0 to 4294967295 --- 1 F300 0
" 737D Disconnect Switch 1 Phase A / Three-pole
Closed
0 to 4294967295 --- 1 F300 0
" 737F Disconnect Switch 1 Phase A / Three-pole
Opened
0 to 4294967295 --- 1 F300 0
" 7381 Disconnect Switch 1 Phase B Closed 0 to 4294967295 --- 1 F300 0
" 7383 Disconnect Switch 1 Phase B Opened 0 to 4294967295 --- 1 F300 0
" 7385 Disconnect Switch 1 Phase C Closed 0 to 4294967295 --- 1 F300 0
" 7387 Disconnect Switch 1 Phase C Opened 0 to 4294967295 --- 1 F300 0
" 7389 Disconnect Switch 1 Operate Time 0 to 65535 ms 1 F003 70
" 738B Disconnect Switch 1 Open Seal In 0 to 65.535 s 0.001 F001 0
" 738C Disconnect Switch 1 Close Seal In 0 to 65.535 s 0.001 F001 0
" 738D Disconnect Switch 1 Alarm Delay 0 to 65.535 s 0.001 F003 0
" 738F Disconnect Switch 1 Push Button Control 0 to 1 --- 1 F102 0 (Disabled)
" 7390 Disconnect Switch 1 Tagging 0 to 1 --- 1 F102 0 (Disabled)
" 7391 Disconnect Switch 1 Substitution 0 to 1 --- 1 F102 0 (Disabled)
" 7392 Disconnect Switch 1 Bypass 0 to 1 --- 1 F102 0 (Disabled)
