CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-149
2
" A0C4 Summator 1 Pickup –2000000 to
2000000
--- 0.001 F004 1000000
" A0C6 Summator 1 Hysteresis 0.1 to 50 % 0.1 F001 30
" A0C7 Summator 1 Input (6 items) 0 to 65535 --- 1 F600 0
" A0CD Summator 1 Scale Factor (6 items) –2000 to 2000 --- 0.000
001
F004 1000000
" A0D9 Summator 1 Position Selector (6 items) 0 to 4294967295 --- 1 F300 0
" A0E5 Summator 1 Units --- --- --- F207 (none)
" A0E7 Summator 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" A0E8 Summator 1 Per-Unit Base 1 to 2000000 --- 1 F004 1
" A0EA ...Repeated for Summator 2
" A114 ...Repeated for Summator 3
" A13E ...Repeated for Summator 4
" A168 ...Repeated for Summator 5
" A192 ...Repeated for Summator 6
Current Unbalance Actual Values (Read Only)
M60 A200 Current Amp Unbalance 0 to 100 % 0.1 F001 0
Selector Switch Actual Values (Read Only)
All except B90 A210 Selector Switch 1 Position 1 to 7 --- 1 F001 0
" A211 Selector Switch 2 Position 1 to 7 --- 1 F001 1
Selector Switch Settings (Read/Write) (2 Modules)
All except B90 A280 Selector 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" A281 Selector 1 Range 1 to 7 --- 1 F001 7
" A282 Selector 1 Timeout 3 to 60 s 0.1 F001 50
" A283 Selector 1 Step Up 0 to 4294967295 --- 1 F300 0
" A285 Selector 1 Step Mode 0 to 1 --- 1 F083 0 (Time-out)
" A286 Selector 1 Acknowledge 0 to 4294967295 --- 1 F300 0
" A288 Selector 1 Bit0 0 to 4294967295 --- 1 F300 0
" A28A Selector 1 Bit1 0 to 4294967295 --- 1 F300 0
" A28C Selector 1 Bit2 0 to 4294967295 --- 1 F300 0
" A28E Selector 1 Bit Mode 0 to 1 --- 1 F083 0 (Time-out)
" A28F Selector 1 Bit Acknowledge 0 to 4294967295 --- 1 F300 0
" A291 Selector 1 Power Up Mode 0 to 2 --- 1 F084 0 (Restore)
" A292 Selector 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" A293 Selector 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" A294 Reserved (10 items) --- --- 1 F001 0
" A29E ...Repeated for Selector 2
Expanded B90 Direct Input/Output Status (Read Only)
B90 A300 Direct Device States, one per register (16
items)
0 to 1 --- 1 F155 0 (Offline)
" A310 Direct Input States, one per register (256
items)
0 to 1 --- 1 F108 0 (Off)
Digital Counter (Read/Write Setting) (8 Modules)
All except B90 A300 Digital Counter 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" A301 Digital Counter 1 Name --- --- --- F205 “Counter 1"
" A307 Digital Counter 1 Units --- --- --- F206 (none)
" A30A Digital Counter 1 Block 0 to 4294967295 --- 1 F300 0
" A30C Digital Counter 1 Up 0 to 4294967295 --- 1 F300 0
