CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-151
2
" A572 ...Repeated for PID 4
Volts Per Hertz (Read/Write Grouped Setting) (2 Modules)
G30, G60, L90,
T60
A580 Volts Per Hertz 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" A581 Volts Per Hertz 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
" A582 Volts Per Hertz 1 Pickup 0.8 to 4 pu 0.01 F001 80
" A583 Volts Per Hertz 1 Curves 0 to 7 --- 1 F240 0 (Definite
Time)
" A584 Volts Per Hertz 1 TD Multiplier 0.05 to 600 --- 0.01 F001 100
" A585 Volts Per Hertz 1 Block 0 to 4294967295 --- 1 F300 0
" A587 Volts Per Hertz 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" A588 Volts Per Hertz 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" A589 Volts Per Hertz 1 T Reset 0 to 1000 s 0.1 F001 10
" A58A Volts Per Hertz 1 Voltage Mode 0 to 1 --- 1 F186 0 (Phase-to-
Ground)
" A58B ...Repeated for Volts Per Hertz 2
Volts Per Hertz Actual Values (Read Only) (2 Modules)
G30, G60, L90,
T60
A5A0 Volts Per Hertz 1 0 to 65.535 pu 0.001 F001 0
" A5A1 Volts Per Hertz 2 0 to 65.535 pu 0.001 F001 0
FlexCurves C and D (Read/Write Setting)
All except C30 A600 FlexCurve C (120 items) 0 to 65535 ms 1 F011 0
" A680 FlexCurve D (120 items) 0 to 65535 ms 1 F011 0
Annunciator (Read/Write Setting)
All A700 Annunciator Alarm Input (96 items) 0 to 4294967295 --- 1 F300 0
" A7C0 Clear Latched Alarms 0 to 4294967295 --- 1 F300 0
Annunciator Actual Values (Read Only)
All A7D0 Annunciator Acknowledge or Reset Alarm
(3 items)
0 to 4294967295 --- 1 F003 0
" A7D6 Annunciator Input States (3 items) 0 to 4294967295 --- 1 F003 0
" A7DC Annunciator Latched States (3 items) 0 to 4294967295 --- 1 F003 0
" A7E2 Annunciator Flashing States (3 items) 0 to 4294967295 --- 1 F003 0
Pilot POTT (1P) (Read/Write Setting)
D60, L90 A800 POTT 1P Scheme Function 0 to 1 --- 1 F102 0 (Disabled)
" A801 POTT 1P Permissive Echo 0 to 2 --- 1 F199 0 (Disabled)
" A802 POTT 1P Rx Pickup Delay 0 to 65.535 s 0.001 F001 0
" A803 POTT 1P Trans Block Pickup Delay 0 to 65.535 s 0.001 F001 20
" A804 POTT 1P Trans Block Reset Delay 0 to 65.535 s 0.001 F001 90
" A805 POTT 1P Echo Duration 0 to 65.535 s 0.001 F001 100
" A806 POTT 1P Echo Lockout 0 to 65.535 s 0.001 F001 250
" A807 POTT 1P Line End Open Pickup Delay 0 to 65.535 s 0.001 F001 50
" A808 POTT 1P Seal In Delay 0 to 65.535 s 0.001 F001 0
" A809 POTT 1P Ground Directional Overcurrent
Forward
0 to 4294967295 --- 1 F300 0
" A80B POTT 1P Number of Communication Bits 0 to 2 --- 1 F198 0 (1)
" A80C POTT 1P Rx1 0 to 4294967295 --- 1 F300 0
" A80E POTT 1P Rx2 0 to 4294967295 --- 1 F300 0
" A810 POTT 1P Rx3 0 to 4294967295 --- 1 F300 0
" A812 POTT 1P Rx4 0 to 4294967295 --- 1 F300 0
Products Address Register name Range Units Step Format Default
