2-152 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" A814 POTT 1P Target 0 to 2 --- 1 F109 0 (Self-reset)
" A815 POTT 1P Event 0 to 1 --- 1 F102 0 (Disabled)
" A816 POTT 1P Echo Condition 0 to 4294967295 --- 1 F300 0
" A818 POTT 1P Scheme Block 0 to 4294967295 --- 1 F300 0
" A81A Reserved (22 items) 0 to 1 --- 1 F001 0
Pilot POTT1 (1P) (Read/Write Setting)
D60, L90 A830 POTT1 1P Scheme Function 0 to 1 --- 1 F102 0 (Disabled)
" A831 POTT1 1P Permissive Echo 0 to 2 --- 1 F199 0 (Disabled)
" A832 POTT1 1P Rx Pickup Delay 0 to 65.535 s 0.001 F001 0
" A833 POTT1 1P Trans Block Pickup Delay 0 to 65.535 s 0.001 F001 20
" A834 POTT1 1P Trans Block Reset Delay 0 to 65.535 s 0.001 F001 90
" A835 POTT1 1P Echo Duration 0 to 65.535 s 0.001 F001 100
" A836 POTT1 1P Echo Lockout 0 to 65.535 s 0.001 F001 250
" A837 POTT1 1P Line End Open Pickup Delay 0 to 65.535 s 0.001 F001 50
" A838 POTT1 1P Seal In Delay 0 to 65.535 s 0.001 F001 0
" A839 POTT1 1P Ground Directional Overcurrent
Forward
0 to 4294967295 --- 1 F300 0
" A83B POTT1 1P Number of Communication Bits 0 to 2 --- 1 F198 0 (1)
" A83C POTT1 1P Rx1 0 to 4294967295 --- 1 F300 0
" A83E POTT1 1P Rx2 0 to 4294967295 --- 1 F300 0
" A840 POTT1 1P Rx3 0 to 4294967295 --- 1 F300 0
" A842 POTT1 1P Rx4 0 to 4294967295 --- 1 F300 0
" A844 POTT1 1P Target 0 to 2 --- 1 F109 0 (Self-reset)
" A845 POTT1 1P Event 0 to 1 --- 1 F102 0 (Disabled)
" A846 POTT1 1P Echo Condition 0 to 4294967295 --- 1 F300 0
" A848 POTT1 1P Scheme Block 0 to 4294967295 --- 1 F300 0
" A84A POTT1 1P OC Fwd2 0 to 4294967295 --- 1 F300 0
" A84C POTT1 1P OC Fwd2 0 to 4294967295 --- 1 F300 0
" A84E Reserved (22 items) 0 to 1 --- 1 F001 0
Pilot Blocking 1 (1P) (Read/Write Setting)
D60, L90 A864 Blocking 1 Scheme 1P Function 0 to 1 --- 1 F102 0 (Disabled)
" A865 Blocking 1 Scheme 1P Block 0 to 4294967295 --- 1 F300 0
" A867 Block 1 1P Rx Coord Pickup Delay 0 to 65.535 s 0.001 F001 10
" A868 Block 1 1P Transient Block Pickup Delay 0 to 65.535 s 0.001 F001 30
" A869 Block 1 1P Transient Block Reset Delay 0 to 65.535 s 0.001 F001 90
" A86A Blocking 1 Scheme 1P Seal in Delay 0 to 65.535 s 0.001 F001 0
" A86B Blocking 1 Scheme 1P Dir Fwd 1 0 to 4294967295 --- 1 F300 0
" A86D Blocking 1 Scheme 1P Dir Fwd 2 0 to 4294967295 --- 1 F300 0
" A86F Blocking 1 Scheme 1P Dir Fwd 3 0 to 4294967295 --- 1 F300 0
" A871 Blocking 1 Scheme 1P Dir Rev 1 0 to 4294967295 --- 1 F300 0
" A873 Blocking 1 Scheme 1P Dir Rev 2 0 to 4294967295 --- 1 F300 0
" A875 Blocking 1 Scheme 1P Dir Rev 3 0 to 4294967295 --- 1 F300 0
" A877 Blocking 1 Scheme 1P Force Tx Stop 1 0 to 4294967295 --- 1 F300 0
" A879 Blocking 1 Scheme 1P Force Tx Stop 2 0 to 4294967295 --- 1 F300 0
" A87B Blocking 1 Scheme 1P Comm Bits 0 to 2 --- 1 F198 0 (1)
" A87C Blocking 1 Scheme 1P Rx1 0 to 4294967295 --- 1 F300 0
" A87E Blocking 1 Scheme 1P Rx2 0 to 4294967295 --- 1 F300 0
