3-220 UR FAMILY – COMMUNICATIONS GUIDE
MODEL IMPLEMENTATION CONFORMANCE STATEMENT (MICS) CHAPTER 3: IEC 61850 COMMUNICATION
3
RlyUTCTms INS Represents the relay UTC time in seconds elapsed since 00:00:00 January 1, 1970.
Mapped to Modbus register 41A0h value, that is, "Relay time clock set time"
register value after converting to UTC (if time zone and DST is used).
LPHD
RrtdComFail SPS RRTD communication failure.
The RRTD COMM FAIL operand.
LPHD
Rs SPS Autoreclose has been reset either manually or by the rest timer.
The AR RESET operand.
Rec13pRREC
RsOp SPS Target resetting - General indication (binary input).
The RESET OP operand value.
TgtRsIHMI
RsOpLoc SPS Target resetting - General indication (binary input).
The RESET OP (OPERAND) operand value.
TgtRsIHMI
RsOpPB SPS Target resetting - General indication (binary input).
The RESET OP (PUSHBUTTON) operand value.
TgtRsIHMI
RsOpRem SPS Target resetting - General indication (binary input).
The RESET OP (COMMS) operand value.
TgtRsIHMI
RsTms INS The UTC time of the last clear in seconds elapsed since 00:00:00 January 1, 1970.
The LAST CLEARED DATE actual value.
OscRDRE
RtdTrbl SPS RTD trouble.
The RTD TROUBLE operand.
LPHD
Running SPS Indicate the motor is running.
The MOTOR RUNNING operand.
MotThmPTTR
RvOp SPS Fault direction is reverse.
The NEG SEQ DIR OC1 REV operand.
The NTRL DIR OC1 REV operand.
NegDocRDIR, NeuDocRDIR
RX1 SPS Pulse received on channel 1 or 2.
The 87PC RX1 operand.
PhCmp1PDIF
RxGooseOff SPS One or more RxGOOSE is not responding.
The RxGOOSE OFF operand.
LPHD
Sat1 SPS Indicates CT saturation is detected.
The BUS 1 SAT A/B/C operand.
B_DifPDIF, BusDifPDIF
Sat1 SPS Indicates phase saturation of differential is detected per phase
The STATOR DIFF1 SAT A/B/C operand.
SttDifPDIF
SbstCls SPS Manually substituted to close.
The BREAKER 1 SUBD CLSD operand.
Bkr0XCBR
SbstOpn SPS Manually substituted to open.
The BREAKER 1 SUBD OPEN operand.
Bkr0XCBR
SecDataClr SPC Command CLEAR SECURITY DATA, TRUE = CLEAR SECURITY DATA SecGSAL
SecEna ENG RxRGOOSE1 Security Ena setting: 0=None; 1=Signature; 2=Signature and
Encryption. Otherwise ignored.
LGOS
SecEthFail SPS Second Ethernet failure.
The SECOND ETHERNET FAIL operand.
LPHD
SecondOfDay INS Represents integer number of seconds past midnight (Range1-86400).
The SecondOfDay actual value in seconds.
TmDayGAPC
SeqTO SPS The incomplete sequence timer timed out.
The AR INCOMPLETE SEQ operand.
Rec13pRREC
SHAmpAng MV Sub harmonic current angle.
SH CURRENT ANGLE in degrees.
SubHaPHIZ
ShotCnt1 SPS Autoreclosec shot count is equal to the number indicated by the data instance
number.
The AR SHOT CNT=1 operand.
Rec13pRREC, Rec3pRREC
ShrtCirc SPS Short circuit detected.
The RRTD RTD 1 SHORTED operand.
The RTD Ip 1 SHORTED operand.
PRTDsSTMP, RRTDsSTMP
Sim SPC Simulated GOOSE values or simulated sampled measurand values are used
instead of original values since they are first received
LPHD
Data object
name
CDC Semantics Used in logical nodes…
