2-34 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
Source Demand Peaks (Read Only Non-Volatile) (4 or 6 Modules)
B30, C60, D60,
F35, F60, G60,
L60, L90, N60,
T60
1E80 Source 1 Demand Ia Maximum 0 to 999999.999 A 0.001 F060 0
" 1E82 Source 1 Demand Ia Maximum Date 0 to 4294967295 --- 1 F050 0
" 1E84 Source 1 Demand Ib Maximum 0 to 999999.999 A 0.001 F060 0
" 1E86 Source 1 Demand Ib Maximum Date 0 to 4294967295 --- 1 F050 0
" 1E88 Source 1 Demand Ic Maximum 0 to 999999.999 A 0.001 F060 0
" 1E8A Source 1 Demand Ic Maximum Date 0 to 4294967295 --- 1 F050 0
" 1E8C Source 1 Demand Watt Maximum 0 to 999999.999 W 0.001 F060 0
" 1E8E Source 1 Demand Watt Maximum Date 0 to 4294967295 --- 1 F050 0
" 1E90 Source 1 Demand Var 0 to 999999.999 var 0.001 F060 0
" 1E92 Source 1 Demand Var Maximum Date 0 to 4294967295 --- 1 F050 0
" 1E94 Source 1 Demand Va Maximum 0 to 999999.999 VA 0.001 F060 0
" 1E96 Source 1 Demand Va Maximum Date 0 to 4294967295 --- 1 F050 0
" 1E98 Reserved (8 items) --- --- --- F001 0
" 1EA0 ...Repeated for Source 2
" 1EC0 ...Repeated for Source 3
" 1EE0 ...Repeated for Source 4
B30, F35, N60,
T60
1F00 ...Repeated for Source 5
" 1F20 ...Repeated for Source 6
Source Voltage THD and Harmonics (Read Only) (2, 4, or 6 Modules)
(For F60, if order code has HIZ DSP, then 0 modules)
C70, D60, F35,
F60, G30, G60,
L30, L90, N60,
T60
1F80 Source 1 Va THD 0 to 99.9 --- 0.1 F001 0
" 1F81 Source 1 Va Harmonics - 2nd to 25th (24
items)
0 to 99.9 --- 0.1 F001 0
" 1F99 Source 1 Vb THD 0 to 99.9 --- 0.1 F001 0
" 1F9A Source 1 Vb Harmonics - 2nd to 25th (24
items)
0 to 99.9 --- 0.1 F001 0
" 1FB2 Source 1 Vc THD 0 to 99.9 --- 0.1 F001 0
" 1FB3 Source 1 Vc Harmonics - 2nd to 25th (24
items)
0 to 99.9 --- 0.1 F001 0
" 1FCB ...Repeated for Source 2
C70, D60, F35,
F60, G30, G60,
L90, N60, T60
2016 ...Repeated for Source 3
" 2061 ...Repeated for Source 4
C70, F35, N60,
T60
20AC ...Repeated for Source 5
" 20F7 ...Repeated for Source 6
Control Pushbuttons (Read/Write Setting) (7 Modules)
All 2142 Control Pushbutton 1 ID 0 to 1 --- 1 F636 "CTRL PB 1"
" 214C Control Pushbutton 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 214D Control Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 214E ...Repeated for Control Pushbutton 2
" 215A ...Repeated for Control Pushbutton 3
Products Address Register name Range Units Step Format Default

GE b30 Specifications

General

Model	b30
Manufacturer	GE
Coil Voltage	N/A (Solid State Relay)
Coil Power	N/A (Solid State Relay)
Mechanical Life	N/A (Solid State Relay)
Electrical Life	N/A (Solid State Relay)
