CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-35
2
" 2166 ...Repeated for Control Pushbutton 4
" 2172 ...Repeated for Control Pushbutton 5
" 217E ...Repeated for Control Pushbutton 6
" 218A ...Repeated for Control Pushbutton 7
Bus Actuals (Read Only) (6 Modules)
B90 21D0 Bus Zone 1 Differential Magnitude 0 to 999999.999 A 0.001 F060 0
" 21D4 Bus Zone 1 Differential Angle -359.9 to 0 degrees 0.1 F002 0
" 21D5 Bus Zone 1 Restraint Magnitude 0 to 999999.999 A 0.001 F060 0
" 21D7 Bus Zone 1 Restraint Angle -359.9 to 0 degrees 0.1 F002 0
" 21D8 Bus Zone 1 Maximum CT 0 to 50000 --- 1 F060 1
" 21DA Reserved (4 items) --- --- --- F001 0
" 21DE ...Repeated for Bus Zone 2
" 21EC ...Repeated for Bus Zone 3
" 21FA ...Repeated for Bus Zone 4
" 2208 ...Repeated for Bus Zone 5
" 2216 ...Repeated for Bus Zone 6
Breaker Arcing Current Commands (Read/Write Command) (2, 3, 4, or 6 Modules)
B30, C60, C70,
D30, D60, F35,
F60, G30, G60,
L30, L60, L90,
M60, T35, T60
2224 Breaker 1 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
" 2225 Breaker 2 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
B30, C60, C70,
F35, F60, L90,
T35, T60
2226 Breaker 3 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
B30, C60, F35,
F60, L90, T35,
T60
2227 Breaker 4 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
B30, F35, T35,
T60
2228 Breaker 5 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
" 2229 Breaker 6 Arcing Current Clear Command 0 to 1 --- 1 F126 0 (No)
Passwords Unauthorized Access (Read/Write Command)
All 2230 Reset Unauthorized Access 0 to 1 --- 1 F126 0 (No)
High Impedance Fault Detection (Hi-Z) Commands (Read/Write Command)
F60 2240 Hi-Z Clear Oscillography 0 to 1 --- 1 F126 0 (No)
" 2241 Hi-Z Oscillography Force Trigger 0 to 1 --- 1 F126 0 (No)
" 2242 Hi-Z Oscillography Force Algorithm Capture 0 to 1 --- 1 F126 0 (No)
" 2243 Hi-Z Reset Sigma Values 0 to 1 --- 1 F126 0 (No)
Hi-Z Status (Read Only)
F60 2250 Hi-Z Status 0 to 9 --- 1 F187 0 (NORMAL)
" 2251 Hi-Z Phase A Arc Confidence 0 to 100 --- 1 F001 0
" 2252 Hi-Z Phase B Arc Confidence 0 to 100 --- 1 F001 0
" 2253 Hi-Z Phase C Arc Confidence 0 to 100 --- 1 F001 0
" 2254 Hi-Z Neutral Arc Confidence 0 to 100 --- 1 F001 0
Hi-Z Records (Read Only) (4 Modules)
F60 2260 Hi-Z Capture 1 Trigger Type 0 to 6 --- 1 F188 0 (NONE)
" 2261 Hi-Z Capture 1 Time 0 to 1 --- 1 F050 0
" 2263 ...Repeated for Hi-Z Capture 2
" 2266 ...Repeated for Hi-Z Capture 3
