2-36 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 2269 ...Repeated for Hi-Z Capture 4
Hi-Z RMS Records (Read Only) (4 Modules)
F60 2270 Hi-Z RMS Capture 1 Trigger Type 0 to 6 --- 1 F188 0 (NONE)
" 2271 Hi-Z RMS Capture 1 Time 0 to 1 --- 1 F050 0
" 2273 ...Repeated for Hi-Z RMS Capture 2
" 2276 ...Repeated for Hi-Z RMS Capture 3
" 2279 ...Repeated for Hi-Z RMS Capture 4
Source Current THD (Read Only) (6 Modules)
L60 22A0 Source 1 Ia THD 0 to 100 % 0.1 F001 0
" 22A1 Source 1 Ib THD 0 to 100 % 0.1 F001 0
" 22A2 Source 1 Ic THD 0 to 100 % 0.1 F001 0
" 22A3 Source 1 In THD 0 to 100 % 0.1 F001 0
" 22A4 ...Repeated for Source 2
" 22A8 ...Repeated for Source 3
" 22AC ...Repeated for Source 4
" 22B0 ...Repeated for Source 5
" 22B4 ...Repeated for Source 6
Transformer Differential and Restraint (Read Only)
G30, T35, T60 2300 Transformer Reference Winding 1 to 6 --- 1 F001 1
" 2301 Transformer Differential Phasor Iad
Magnitude
0 to 30 pu 0.001 F001 0
" 2302 Transformer Differential Phasor Iad Angle -359.9 to 0 degrees 0.1 F002 0
" 2303 Transformer Restraint Phasor Iar
Magnitude
0 to 30 pu 0.001 F001 0
" 2304 Transformer Restraint Phasor Iar Angle -359.9 to 0 degrees 0.1 F002 0
" 2305 Transformer Differential 2nd Harm Iad
Magnitude
0 to 999.9 % fo 0.1 F001 0
" 2306 Transformer Differential 2nd Harm Iad
Angle
-359.9 to 0 degrees 0.1 F002 0
" 2307 Transformer Differential 5th Harm Iad
Magnitude
0 to 999.9 % fo 0.1 F001 0
" 2308 Transformer Differential 5th Harm Iad
Angle
-359.9 to 0 degrees 0.1 F002 0
" 2309 Transformer Differential Phasor Ibd
Magnitude
0 to 30 pu 0.001 F001 0
" 230A Transformer Differential Phasor Ibd Angle -359.9 to 0 degrees 0.1 F002 0
" 230B Transformer Restraint Phasor Ibr
Magnitude
0 to 30 pu 0.001 F001 0
" 230C Transformer Restraint Phasor Ibr Angle -359.9 to 0 degrees 0.1 F002 0
" 230D Transformer Differential 2nd Harm Ibd
Magnitude
0 to 999.9 % fo 0.1 F001 0
" 230E Transformer Differential 2nd Harm Ibd
Angle
-359.9 to 0 degrees 0.1 F002 0
" 230F Transformer Differential 5th Harm Ibd
Magnitude
0 to 999.9 % fo 0.1 F001 0
" 2310 Transformer Differential 5th Harm Ibd
Angle
-359.9 to 0 degrees 0.1 F002 0
" 2311 Transformer Differential Phasor Icd
Magnitude
0 to 30 pu 0.001 F001 0
" 2312 Transformer Differential Phasor Icd Angle -359.9 to 0 degrees 0.1 F002 0
Products Address Register name Range Units Step Format Default
