CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-37
2
" 2313 Transformer Restraint Phasor Icr
Magnitude
0 to 30 pu 0.001 F001 0
" 2314 Transformer Restraint Phasor Icr Angle -359.9 to 0 degrees 0.1 F002 0
" 2315 Transformer Differential 2nd Harm Icd
Magnitude
0 to 999.9 % fo 0.1 F001 0
" 2316 Transformer Differential 2nd Harm Icd
Angle
-359.9 to 0 degrees 0.1 F002 0
" 2317 Transformer Differential 5th Harm Icd
Magnitude
0 to 999.9 % fo 0.1 F001 0
" 2318 Transformer Differential 5th Harm Icd
Angle
-359.9 to 0 degrees 0.1 F002 0
Transformer Thermal Inputs Actual Values (Read Only)
G30, T35, T60 2330 Transformer Top Oil Temperature 0 to 300 °C 1 F002 0
" 2331 Transformer Hottest Spot Temperature 0 to 300 °C 1 F002 0
" 2332 Transformer Aging Factor 0 to 6553.5 PU 0.1 F001 0
" 2333 Transformer Daily Loss of Life 0 to 500000 Hours 1 F060 0
Transformer Thermal Inputs Actual Values (Read Only Non-Volatile)
G30, T35, T60 2335 Transformer Loss of Life 0 to 500000 Hours 1 F060 0
Fault Location (Read Only) (1, 2, or 5 Modules)
C60, D30, D60,
F35, F60, L30,
L60, L90
2340 Fault 1 Prefault Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 2342 Fault 1 Prefault Phase A Current Angle -359.9 to 0 degrees 0.1 F002 0
" 2343 Fault 1 Prefault Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 2345 Fault 1 Prefault Phase B Current Angle -359.9 to 0 degrees 0.1 F002 0
" 2346 Fault 1 Prefault Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 2348 Fault 1 Prefault Phase C Current Angle -359.9 to 0 degrees 0.1 F002 0
" 2349 Fault 1 Prefault Phase A Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
" 234B Fault 1 Prefault Phase A Voltage Angle -359.9 to 0 degrees 0.1 F002 0
" 234C Fault 1 Prefault Phase B Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
" 234E Fault 1 Prefault Phase B Voltage Angle -359.9 to 0 degrees 0.1 F002 0
" 234F Fault 1 Prefault Phase C Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
" 2351 Fault 1 Prefault Phase C Voltage Angle -359.9 to 0 degrees 0.1 F002 0
" 2352 Fault 1 Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 2354 Fault 1 Phase A Current Angle -359.9 to 0 degrees 0.1 F002 0
" 2355 Fault 1 Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 2357 Fault 1 Phase B Current Angle -359.9 to 0 degrees 0.1 F002 0
" 2358 Fault 1 Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
" 235A Fault 1 Phase C Current Angle -359.9 to 0 degrees 0.1 F002 0
" 235B Fault 1 Phase A Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
" 235D Fault 1 Phase A Voltage Angle -359.9 to 0 degrees 0.1 F002 0
" 235E Fault 1 Phase B Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
" 2360 Fault 1 Phase B Voltage Angle -359.9 to 0 degrees 0.1 F002 0
" 2361 Fault 1 Phase C Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
" 2363 Fault 1 Phase C Voltage Angle -359.9 to 0 degrees 0.1 F002 0
" 2364 Fault 1 Type 0 to 11 --- 1 F148 0 (NA)
" 2365 Fault 1 Location based on Line length units
(km or miles)
-3276.7 to 3276.7 --- 0.1 F002 0
Products Address Register name Range Units Step Format Default
