CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-39
2
" 24AC Restraint Square Current IB 0 to 999999.999 A 0.001 F060 0
" 24AE Restraint Square Current IC 0 to 999999.999 A 0.001 F060 0
" 24B0 Restraint Current IA 0 to 999999.999 A 0.001 F060 0
" 24B2 Restraint Current IB 0 to 999999.999 A 0.001 F060 0
" 24B4 Restraint Current IC 0 to 999999.999 A 0.001 F060 0
" 24B6 Differential Current IG Magnitude 0 to 999999.999 A 0.001 F060 0
" 24B8 Differential Current IG Angle -359.9 to 0 degrees 0.1 F002 0
" 24B9 Restraint Current IG 0 to 999999.999 A 0.001 F060 0
" 24BB Local IG Magnitude 0 to 999999.999 A 0.001 F060 0
" 24BD Local IG Angle -359.9 to 0 degrees 0.1 F002 0
" 24BE Terminal 1 IG Magnitude 0 to 999999.999 A 0.001 F060 0
" 24C0 Terminal 1 IG Angle -359.9 to 0 degrees 0.1 F002 0
" 24C1 Terminal 2 IG Magnitude 0 to 999999.999 A 0.001 F060 0
" 24C3 Terminal 2 IG Angle -359.9 to 0 degrees 0.1 F002 0
Current Differential 87L Composite Voltage Actuals (Read Only)
L90 24C4 Line Current Differential (87L) Local
Composite Voltage Magnitude
0 to 999999.999 V 0.001 F060 0
" 24C6 Line Current Differential (87L) Local
Composite Voltage Angle
–359.9 to 0 degrees 0.1 F002 0
" 24C7 Line Current Differential (87L) Terminal 1
Composite Voltage Magnitude
0 to 999999.999 V 0.001 F060 0
" 24C9 Line Current Differential (87L) Terminal 1
Composite Voltage Angle
–359.9 to 0 degrees 0.1 F002 0
" 24CA Line Current Differential (87L) Terminal 2
Composite Voltage Magnitude
0 to 999999.999 V 0.001 F060 0
" 24CC Line Current Differential (87L) Terminal 2
Composite Voltage Angle
–359.9 to 0 degrees 0.1 F002 0
87L Second Harmonics Differential Current (Read Only)
L30, L90 24CD Line Current Differential (87L) Second
Harmonic Iad Magnitude
0 to 999999.999 A 0.001 F060 0
" 24CF Line Current Differential (87L) Second
Harmonic Ibd magnitude
0 to 999999.999 A 0.001 F060 0
" 24D1 Line Current Differential (87L) Second
Harmonic Icd Magnitude
0 to 999999.999 A 0.001 F060 0
Fault Location Loop Impedance (Read Only) (5 Modules)
C60, D30, D60,
F35, F60, L30,
L60, L90
24D3 Fault Loop Resist 0 to 9999.99 ohm 0.01 F004 0
" 24D5 Fault Loop React -9999.99 to 9999.99 ohm 0.01 F004 0
" 24D7 ...Repeated for module 2
" 24DB ...Repeated for module 3
" 24DF ...Repeated for module 4
" 24E3 ...Repeated for module 5
Fault Location Multiend (Read Only) (5 Modules)
C60, D30, D60,
F35, F60, L30,
L60, L90
24E7 Fault Resistance 0 to 9999.99 ohm 0.01 F004 0
" 24E9 Fault Segment 0 to 3 --- 1 F001 0
" 24EA ...Repeated for module 2
" 24ED ...Repeated for module 3
" 24F0 ...Repeated for module 4
Products Address Register name Range Units Step Format Default
