GE b30 Communications Guide

CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-67
2
" 46D6 ...Repeated for Incipient Cable Fault
Detector 4
" 46E2 ...Repeated for Incipient Cable Fault
Detector 5
" 46EE ...Repeated for Incipient Cable Fault
Detector 6
Breaker Control (Read/Write Settings) (2, 3, 4, or 6 Modules)
All except B90 4740 Breaker 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 4741 Breaker 1 Name --- --- --- F206 “Bkr 1"
" 4744 Breaker 1 Mode 0 to 1 --- 1 F157 0 (3-Pole)
" 4745 Breaker 1 Open 0 to 4294967295 --- 1 F300 0
" 4747 Breaker 1 Close 0 to 4294967295 --- 1 F300 0
" 4749 Breaker 1 Phase A / Three-pole Closed 0 to 4294967295 --- 1 F300 0
" 474B Breaker 1 Phase B Closed 0 to 4294967295 --- 1 F300 0
" 474D Breaker 1 Phase C Closed 0 to 4294967295 --- 1 F300 0
" 474F Breaker 1 External Alarm 0 to 4294967295 --- 1 F300 0
" 4751 Breaker 1 Alarm Delay 0 to 65.535 s 0.001 F003 0
" 4753 Breaker 1 Pushbutton Control 0 to 1 --- 1 F102 0 (Disabled)
" 4754 Breaker 1 Manual Close Recall Time 0 to 65.535 s 0.001 F003 0
" 4756 Breaker 1 Out of Service 0 to 4294967295 --- 1 F300 0
" 4758 Breaker 1 Block Open 0 to 4294967295 --- 1 F300 0
" 475A Breaker 1 Block Close 0 to 4294967295 --- 1 F300 0
" 475C Breaker 1 Phase A / Three-pole Opened 0 to 4294967295 --- 1 F300 0
" 475E Breaker 1 Phase B Opened 0 to 4294967295 --- 1 F300 0
" 4760 Breaker 1 Phase C Opened 0 to 4294967295 --- 1 F300 0
" 4762 Breaker 1 Operate Time 0 to 65535 ms 1 F003 70
" 4764 Breaker 1 Open Seal In 0 to 65.535 s 0.001 F003 0
" 4766 Breaker 1 Tagging 0 to 1 --- 1 F102 0 (Disabled)
" 4767 Breaker 1 Substitution 0 to 1 --- 1 F102 0 (Disabled)
" 4768 Breaker 1 Bypass 0 to 1 --- 1 F102 0 (Disabled)
" 4769 Breaker 1 AR Block 0 to 1 --- 1 F102 0 (Disabled)
" 476A Breaker 1 Racked In 0 to 4294967295 --- 1 F300 0
" 476C Breaker 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 476D Reserved 0 to 65535 s 1 F001 0
" 476E ...Repeated for Breaker 2
B30, C60, C70,
D60, F60, F35,
L90, N60, T35,
T60
479C ...Repeated for Breaker 3
B30, C60, D60,
F60, F35, L90,
N60, T35, T60
47CA ...Repeated for Breaker 4
B30, F35, N60,
T35, T60
47F8 ...Repeated for Breaker 5
" 4826 ...Repeated for Breaker 6
Breaker Control Actual Values (Read Only) (2, 3, 4, or 6 Modules)
All except B90 4870 Breaker 1 States 0 to 15 --- 1 F281 0 (CLOSED
BIT)
" 4871 ...Repeated for Breaker 2
Products Address Register name Range Units Step Format Default
