2-68 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
B30, C60, C70,
D60, F60, F35,
L90, N60, T35,
T60
4872 ...Repeated for Breaker 3
B30, C60, D60,
F60, F35, L90,
N60, T35, T60
4873 ...Repeated for Breaker 4
B30, F35, N60,
T35, T60
4874 ...Repeated for Breaker 5
" 4875 ...Repeated for Breaker 6
Breaker Control Commands (Read/Write Command) (2, 3, 4, or 6 Modules)
All except B90 4880 Breaker 1 Command 0 to 11 --- 1 F282 0 (CANCEL)
" 4881 ...Repeated for Breaker 2
B30, C60, C70,
D60, F60, F35,
L90, N60, T35,
T60
4882 ...Repeated for Breaker 3
B30, C60, D60,
F60, F35, L90,
N60, T35, T60
4883 ...Repeated for Breaker 4
B30, F35, N60,
T35, T60
4884 ...Repeated for Breaker 5
" 4885 ...Repeated for Breaker 6
Programmable Event Cause LEDs (Read/Write Setting) (9 Modules)
All 48A0 Programmable Event Cause LED 1 Operand 0 to 4294967295 --- 1 F300 0
" 48A2 Programmable Event Cause LED 2 Type 0 to 1 --- 1 F127 1 (Self-Reset)
" 48A3 Programmable Event Cause LED 3 Color 0 to 2 --- 1 F651 0 (ORANGE)
" 48A4 ...Repeated for LED 2
" 48A8 ...Repeated for LED 3
" 48AC ...Repeated for LED 4
" 48B0 ...Repeated for LED 5
" 48B4 ...Repeated for LED 6
" 48B8 ...Repeated for LED 7
" 48BC ...Repeated for LED 8
" 48C0 ...Repeated for LED 9
Compensated Overvoltage (Read/Write Grouped Setting)
D60, L60, L90 48F0 Compensated OV Function 0 to 1 --- 1 F102 0 (Disabled)
" 48F1 Compensated OV Source 0 to 5 --- 1 F167 0 (SRC 1)
" 48F2 Compensated OV Zc Mag 0 to 500 ohm 0.01 F001 200
" 48F3 Compensated OV Zc Ang 30 to 90 degrees 1 F001 90
" 48F4 Compensated OV I_1max 0.01 to 1 pu 0.01 F001 20
" 48F5 Compensated OV STG1 PKP 0.25 to 3 pu 0.001 F001 1300
" 48F6 Compensated OV STG1 Delay 0 to 600 sec 0.01 F001 100
" 48F7 Compensated OV STG2 PKP 0.25 to 3 pu 0.001 F001 1300
" 48F8 Compensated OV STG2 Delay 0 to 600 sec 0.01 F001 100
" 48F9 Compensated OV SGT3 PKP 0.25 to 3 pu 0.001 F001 1300
" 48FA Compensated OV STG3 Delay 0 to 600 sec 0.01 F001 100
" 48FB Compensated OV Block 0 to 4294967295 --- 1 F300 0
" 48FD Compensated OV Target 0 to 2 --- 1 F109 0 (Self-reset)
" 48FE Compensated OV Events 0 to 1 --- 1 F102 0 (Disabled)
Products Address Register name Range Units Step Format Default
