CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-69
2
Demand (Read/Write Setting)
B30, C60, D60,
F35, F60, G60,
L60, L90, N60,
T60
490A Demand Current Method 0 to 2 --- 1 F139 0 (Thermal
Exponential)
" 490B Demand Power Method 0 to 2 --- 1 F139 0 (Thermal
Exponential)
" 490C Demand Interval 0 to 5 --- 1 F132 2 (15 MIN)
" 490D Demand Input 0 to 4294967295 --- 1 F300 0
Demand (Read/Write Command)
B30, C60, D60,
F35, F60, G60,
L60, L90, N60,
T60
490F Demand Clear Record 0 to 1 --- 1 F126 0 (No)
FlexCurves A and B (Read/Write Settings)
All except C30 4910 FlexCurve A (120 items) 0 to 65535 ms 1 F011 0
" 4988 FlexCurve B (120 items) 0 to 65535 ms 1 F011 0
Modbus User Map (Read/Write Setting)
All 4A00 Modbus Address Settings for User Map (256
items)
0 to 65535 --- 1 F001 0
User Displays Settings (Read/Write Setting) (16 Modules)
All 4C00 User-Definable Display 1 Top Line Text --- --- --- F202 “ “
" 4C0A User-Definable Display 1 Bottom Line Text --- --- --- F202 “ “
" 4C14 Modbus Addresses of Display 1 Items (5
items)
0 to 65535 --- 1 F001 0
" 4C19 Reserved (7 items) --- --- --- F001 0
" 4C20 ...Repeated for User-Definable Display 2
" 4C40 ...Repeated for User-Definable Display 3
" 4C60 ...Repeated for User-Definable Display 4
" 4C80 ...Repeated for User-Definable Display 5
" 4CA0 ...Repeated for User-Definable Display 6
" 4CC0 ...Repeated for User-Definable Display 7
" 4CE0 ...Repeated for User-Definable Display 8
" 4D00 ...Repeated for User-Definable Display 9
" 4D20 ...Repeated for User-Definable Display 10
" 4D40 ...Repeated for User-Definable Display 11
" 4D60 ...Repeated for User-Definable Display 12
" 4D80 ...Repeated for User-Definable Display 13
" 4DA0 ...Repeated for User-Definable Display 14
" 4DC0 ...Repeated for User-Definable Display 15
" 4DE0 ...Repeated for User-Definable Display 16
Field Unit Raw Data Actuals (Read Only) (8 Modules)
All except B90,
L60
4E00 Raw Field Data AC1 Mag 0 to 0.001 A 0.001 F003 0
" 4E02 Raw Field Data AC1 Angle 0 to 0.1 degree 0.1 F002 0
" 4E03 Raw Field Data AC2 Mag 0 to 0.001 A 0.001 F003 0
" 4E05 Raw Field Data AC2 Angle 0 to 0.1 degree 0.1 F002 0
" 4E06 Raw Field Data AC3 Mag 0 to 0.001 A 0.001 F003 0
" 4E08 Raw Field Data AC3 Angle 0 to 0.1 degree 0.1 F002 0
" 4E09 Raw Field Data AC4 Mag 0 to 0.001 A 0.001 F003 0
