GE b30 Communications Guide

2-70 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 4E0B Raw Field Data AC4 Angle 0 to 0.1 degree 0.1 F002 0
" 4E0C Raw Field Data AC5 Mag 0 to 0.001 A/V 0.001 F003 0
" 4E0E Raw Field Data AC5 Angle 0 to 0.1 degree 0.1 F002 0
" 4E0F Raw Field Data AC6 Mag 0 to 0.001 A/V 0.001 F003 0
" 4E11 Raw Field Data AC6 Angle 0 to 0.1 degree 0.1 F002 0
" 4E12 Raw Field Data AC7 Mag 0 to 0.001 A/V 0.001 F003 0
" 4E14 Raw Field Data AC7 Angle 0 to 0.1 degree 0.1 F002 0
" 4E15 Raw Field Data AC8 Mag 0 to 0.001 A/V 0.001 F003 0
" 4E17 Raw Field Data AC8 Angle 0 to 0.1 degree 0.1 F002 0
" 4E18 Raw Field Data DC1 0 to 0.001 V 0.001 F002 0
" 4E19 Raw Field Data DC2 0 to 0.001 V 0.001 F002 0
" 4E1A Raw Field Data DC3 0 to 0.001 V 0.001 F002 0
" 4E1B Raw Field Data FCI States (2 items) 0 to 1 --- 1 F500 0
" 4E1D Raw Field Data SI States 0 to 1 --- 1 F500 0
" 4E1E Raw Field Data SI Test States 0 to 1 --- 1 F500 0
" 4E1F Raw Field Data Brick ADC Temperature 0 to 1 degree 1 F002 0
" 4E20 Raw Field Data Brick Transceiver
Temperature
0 to 1 degree 1 F002 0
" 4E21 Raw Field Data Brick Transceiver Voltage 0 to 0.01 V 0.01 F001 0
" 4E22 Raw Field Data Brick Transceiver Current 0 to 1 mA 1 F001 0
" 4E23 Raw Field Data Brick Tx Power 0 to 0.1 dBm 0.1 F002 0
" 4E24 Raw Field Data Brick Rx Power 0 to 0.1 dBm 0.1 F002 0
" 4E25 Raw Field Data Brick Diagnostics (2 items) 0 to 65535 --- 1 F500 0
" 4E27 Raw Field Data Local Transceiver
Temperature
0 to 1 degree 1 F002 0
" 4E28 Raw Field Data Local Transceiver Voltage 0 to 0.01 V 0.01 F001 0
" 4E29 Raw Field Data Local Transceiver Current 0 to 1 mA 1 F001 0
" 4E2A Raw Field Data Local Tx Power 0 to 0.1 dBm 0.1 F002 0
" 4E2B Raw Field Data Local Rx Power 0 to 0.1 dBm 0.1 F002 0
" 4E2C Repeated for Field Unit 2
" 4E58 Repeated for Field Unit 3
" 4E84 Repeated for Field Unit 4
" 4EB0 Repeated for Field Unit 5
" 4EDC Repeated for Field Unit 6
" 4F08 Repeated for Field Unit 7
" 4F34 Repeated for Field Unit 8
FlexLogic (Read/Write Setting)
All 5000 FlexLogic Entry (1024 items) 0 to 4294967295 --- 1 F300 2097152
FlexLogic Timers (Read/Write Setting) (32 Modules)
All 5800 FlexLogic Timer 1 Type 0 to 2 --- 1 F129 0
(millisecond)
" 5801 FlexLogic Timer 1 Pickup Delay 0 to 60000 --- 1 F001 0
" 5802 FlexLogic Timer 1 Dropout Delay 0 to 60000 --- 1 F001 0
" 5803 Reserved (5 items) 0 to 65535 --- 1 F001 0
" 5808 ...Repeated for FlexLogic Timer 2
" 5810 ...Repeated for FlexLogic Timer 3
" 5818 ...Repeated for FlexLogic Timer 4
" 5820 ...Repeated for FlexLogic Timer 5
Products Address Register name Range Units Step Format Default
