GE b30 Communications Guide

CHAPTER 2: MODBUS COMMUNICATION MEMORY MAP
UR FAMILY – COMMUNICATIONS GUIDE 2-71
2
" 5828 ...Repeated for FlexLogic Timer 6
" 5830 ...Repeated for FlexLogic Timer 7
" 5838 ...Repeated for FlexLogic Timer 8
" 5840 ...Repeated for FlexLogic Timer 9
" 5848 ...Repeated for FlexLogic Timer 10
" 5850 ...Repeated for FlexLogic Timer 11
" 5858 ...Repeated for FlexLogic Timer 12
" 5860 ...Repeated for FlexLogic Timer 13
" 5868 ...Repeated for FlexLogic Timer 14
" 5870 ...Repeated for FlexLogic Timer 15
" 5878 ...Repeated for FlexLogic Timer 16
" 5880 ...Repeated for FlexLogic Timer 17
" 5888 ...Repeated for FlexLogic Timer 18
" 5890 ...Repeated for FlexLogic Timer 19
" 5898 ...Repeated for FlexLogic Timer 20
" 58A0 ...Repeated for FlexLogic Timer 21
" 58A8 ...Repeated for FlexLogic Timer 22
" 58B0 ...Repeated for FlexLogic Timer 23
" 58B8 ...Repeated for FlexLogic Timer 24
" 58C0 ...Repeated for FlexLogic Timer 25
" 58C8 ...Repeated for FlexLogic Timer 26
" 58D0 ...Repeated for FlexLogic Timer 27
" 58D8 ...Repeated for FlexLogic Timer 28
" 58E0 ...Repeated for FlexLogic Timer 29
" 58E8 ...Repeated for FlexLogic Timer 30
" 58F0 ...Repeated for FlexLogic Timer 31
" 58F8 ...Repeated for FlexLogic Timer 32
Phase Time Overcurrent (Read/Write Grouped Setting) (2, 4, or 6 Modules)
B30, C60, C70,
D30, D60, F35,
F60, G30, G60,
L30, L60, L90,
M60, N60, T35,
T60
5900 Phase Time Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
" 5901 Phase Time Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
" 5902 Phase Time Overcurrent 1 Input 0 to 1 --- 1 F122 0 (Phasor)
" 5903 Phase Time Overcurrent 1 Pickup 0.02 to 30 pu 0.001 F001 1000
" 5904 Phase Time Overcurrent 1 Curve 0 to 16 --- 1 F103 0 (IEEE Mod
Inv)
" 5905 Phase Time Overcurrent 1 Multiplier 0 to 600 --- 0.01 F001 100
" 5906 Phase Time Overcurrent 1 Reset 0 to 1 --- 1 F104 0
(Instantaneo
us)
" 5907 Phase Time Overcurrent 1 Voltage
Restraint
0 to 1 --- 1 F102 0 (Disabled)
" 5908 Phase TOC 1 Block For Each Phase (3 items) 0 to 4294967295 --- 1 F300 0
" 590F Phase Time Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 5910 Phase Time Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 5911 Reserved (3 items) 0 to 1 --- 1 F001 0
" 5914 ...Repeated for Phase Time Overcurrent 2
Products Address Register name Range Units Step Format Default
