2-72 UR FAMILY – COMMUNICATIONS GUIDE
MEMORY MAP CHAPTER 2: MODBUS COMMUNICATION
2
" 5928 ...Repeated for Phase Time Overcurrent 3
B30, C60, C70,
D60, F35, F60,
L30, L60, L90,
M60, N60, T35,
T60
593C ...Repeated for Phase Time Overcurrent 4
B30, C60, C70,
F35, F60, L90,
M60, N60, T35,
T60
5950 ...Repeated for Phase Time Overcurrent 5
" 5964 ...Repeated for Phase Time Overcurrent 6
Phase Instantaneous Overcurrent (Read/Write Grouped Setting) (2, 4, 6, 8, or 12 Modules)
All except B90,
C30
5A00 Phase Instantaneous Overcurrent 1
Function
0 to 1 --- 1 F102 0 (Disabled)
" 5A01 Phase Instantaneous Overcurrent 1 Signal
Source
0 to 5 --- 1 F167 0 (SRC 1)
" 5A02 Phase Instantaneous Overcurrent 1 Pickup 0.005 to 30 pu 0.001 F001 1000
" 5A03 Phase Instantaneous Overcurrent 1 Delay 0 to 600 s 0.01 F001 0
" 5A04 Phase Instantaneous Overcurrent 1 Reset
Delay
0 to 600 s 0.01 F001 0
" 5A05 Phase IOC1 Block For Each Phase (3 items) 0 to 4294967295 --- 1 F300 0
" 5A0B Phase Instantaneous Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
" 5A0C Phase Instantaneous Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
" 5A0D Reserved (6 items) 0 to 1 --- 1 F001 0
" 5A13 ...Repeated for Phase Instantaneous
Overcurrent 2
B30, C60, C70,
D60, F35, F60,
G30, G60, L30,
L60, L90, M60,
N60, T35, T60
5A26 ...Repeated for Phase Instantaneous
Overcurrent 3
" 5A39 ...Repeated for Phase Instantaneous
Overcurrent 4
B30, C60, C70,
D60, F35, F60,
L90, M60, N60,
T35, T60
5A4C ...Repeated for Phase Instantaneous
Overcurrent 5
" 5A5F ...Repeated for Phase Instantaneous
Overcurrent 6
B30, C60, C70,
F35, F60, L90,
M60, N60, T35,
T60
5A72 ...Repeated for Phase Instantaneous
Overcurrent 7
" 5A85 ...Repeated for Phase Instantaneous
Overcurrent 8
B30, C70, F35,
N60, T35, T60
5A98 ...Repeated for Phase Instantaneous
Overcurrent 9
" 5AAB ...Repeated for Phase Instantaneous
Overcurrent 10
" 5ABE ...Repeated for Phase Instantaneous
Overcurrent 11
" 5AD1 ...Repeated for Phase Instantaneous
Overcurrent 12
