GE Multilin D60 Line Distance Protection System B-45
APPENDIX B B.4 MEMORY MAPPING
B
6859 Blocking Scheme 1P Block 0 to 4294967295 --- 1 F300 0
685B Reserved (2 items) 0 to 1 --- 1 F001 0
Autoreclose 1P 3P (Read/Write Setting)
6860 Autoreclose Mode 0 to 3 --- 1 F080 0 (1 & 3 Pole)
6861 Autoreclose Maximum Number of Shots 1 to 4 --- 1 F001 2
6862 Autoreclose Block Breaker 1 0 to 4294967295 --- 1 F300 0
6864 Autoreclose Close Time Breaker 1 0 to 655.35 s 0.01 F001 10
6865 Autoreclose Breaker Manual Close 0 to 4294967295 --- 1 F300 0
6867 Autoreclose Function 0 to 1 --- 1 F102 0 (Disabled)
6868 Autoreclose Block Time Manual Close 0 to 655.35 s 0.01 F001 1000
6869 Autoreclose 1P Initiate 0 to 4294967295 --- 1 F300 0
686B Autoreclose 3P Initiate 0 to 4294967295 --- 1 F300 0
686D Autoreclose 3P TD Initiate 0 to 4294967295 --- 1 F300 0
686F Autoreclose Multi-Phase Fault 0 to 4294967295 --- 1 F300 0
6871 Autoreclose Breaker 1 Pole Open 0 to 4294967295 --- 1 F300 0
6873 Autoreclose Breaker 3 Pole Open 0 to 4294967295 --- 1 F300 0
6875 Autoreclose 3-Pole Dead Time 1 0 to 655.35 s 0.01 F001 50
6876 Autoreclose 3-Pole Dead Time 2 0 to 655.35 s 0.01 F001 120
6877 Autoreclose Extend Dead T1 0 to 4294967295 --- 1 F300 0
6879 Autoreclose Dead T1 Extension 0 to 655.35 s 0.01 F001 50
687A Autoreclose Reset 0 to 4294967295 --- 1 F300 0
687C Autoreclose Reset Time 0 to 655.35 s 0.01 F001 6000
687D Autoreclose Breaker Closed 0 to 4294967295 --- 1 F300 0
687F Autoreclose Block 0 to 4294967295 --- 1 F300 0
6881 Autoreclose Pause 0 to 4294967295 --- 1 F300 0
6883 Autoreclose Incomplete Sequence Time 0 to 655.35 s 0.01 F001 500
6884 Autoreclose Block Breaker 2 0 to 4294967295 --- 1 F300 0
6886 Autoreclose Close Time Breaker 2 0 to 655.35 s 0.01 F001 10
6887 Autoreclose Transfer 1 to 2 0 to 1 --- 1 F126 0 (No)
6888 Autoreclose Transfer 2 to 1 0 to 1 --- 1 F126 0 (No)
6889 Autoreclose Breaker 1 Fail Option 0 to 1 --- 1 F081 0 (Continue)
688A Autoreclose Breaker 2 Fail Option 0 to 1 --- 1 F081 0 (Continue)
688B Autoreclose 1P Dead Time 0 to 655.35 s 0.01 F001 100
688C Autoreclose Breaker Sequence 0 to 4 --- 1 F082 3 (1 - 2)
688D Autoreclose Transfer Time 0 to 655.35 s 0.01 F001 400
688E Autoreclose Event 0 to 1 --- 1 F102 0 (Disabled)
688F Autoreclose 3P Dead Time 3 0 to 655.35 s 0.01 F001 200
6890 Autoreclose 3P Dead Time 4 0 to 655.35 s 0.01 F001 400
6891 Autoreclose Bus Fault Initiate 0 to 4294967295 s 0.01 F300 0
6893 Autoreclose Initiate Mode 0 to 1 --- 1 F610 0 (Protection AND
CB)
6894 Autoreclose Mode Aut 0 to 3 --- 1 F622 0 (Mode 1 (1 & 3
Pole))
6895 Autoreclose Mode 1 Activation 0 to 4294967295 --- 1 F300 0
6897 Autoreclose Mode 2 Activation 0 to 4294967295 --- 1 F300 0
6899 Autoreclose Mode 3 Activation 0 to 4294967295 --- 1 F300 0
689B Autoreclose Mode 4 Activation 0 to 4294967295 --- 1 F300 0
Pilot Directional Comparison Unblocking Scheme (Read/Write Setting)
68A0 Directional Comparison Unblocking Scheme Function 0 to 1 --- 1 F102 0 (Disabled)
68A1 Directional Comparison Unblocking Block 0 to 4294967295 --- 1 F300 0
68A3 Directional Comparison Unblocking Permissive Echo 0 to 2 --- 1 F199 0 (Disabled)
68A4 Directional Comparison Unblocking Echo Condition 0 to 4294967295 --- 1 F300 0
68A6 DCUB Ground Directional Overcurrent Forward 0 to 4294967295 --- 1 F300 0
68A8 DCUB Ground Directional Overcurrent Reverse 0 to 4294967295 --- 1 F300 0
68AA DCUB Transmit Block Pickup Delay 0 to 65.535 s 0.001 F001 20
Table B–10: MODBUS MEMORY MAP (Sheet 37 of 77)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
