B-44 D60 Line Distance Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
67DC DUTT 1P Event 0 to 1 --- 1 F102 0 (Disabled)
67DD DUTT 1P Block 0 to 4294967295 --- 1 F300 0
67DF Reserved (6 items) 0 to 1 --- 1 F001 0
Pilot PUTT (1P) (Read/Write Setting)
67EA PUTT 1P Scheme Function 0 to 1 --- 1 F102 0 (Disabled)
67EB PUTT 1P Rx Pickup Delay 0 to 65.535 s 0.001 F001 0
67EC PUTT 1P Seal In Delay 0 to 65.535 s 0.001 F001 0
67ED PUTT 1P Number of Communication Bits 0 to 2 --- 1 F198 0 (1)
67EE PUTT 1P Rx1 0 to 4294967295 --- 1 F300 0
67F0 PUTT 1P Rx2 0 to 4294967295 --- 1 F300 0
67F2 PUTT 1P Rx3 0 to 4294967295 --- 1 F300 0
67F4 PUTT 1P Rx4 0 to 4294967295 --- 1 F300 0
67F6 PUTT 1P Target 0 to 2 --- 1 F109 0 (Self-reset)
67F7 PUTT 1P Event 0 to 1 --- 1 F102 0 (Disabled)
67F8 PUTT 1P Block 0 to 4294967295 --- 1 F300 0
67FA Reserved (5 items) 0 to 1 --- 1 F001 0
Pilot Hybrid POTT (1P) (Read/Write Setting)
6820 Hybrid POTT 1P Scheme Function 0 to 1 --- 1 F102 0 (Disabled)
6821 Hybrid POTT 1P Permissive Echo 0 to 2 --- 1 F199 0 (Disabled)
6822 Hybrid POTT 1P Rx Pickup Delay 0 to 65.535 s 0.001 F001 0
6823 Hybrid POTT 1P Trans Block Pickup Delay 0 to 65.535 s 0.001 F001 20
6824 Hybrid POTT 1P Trans Block Reset Delay 0 to 65.535 s 0.001 F001 90
6825 Hybrid POTT 1P Echo Duration 0 to 65.535 s 0.001 F001 100
6826 Hybrid POTT 1P Echo Lockout 0 to 65.535 s 0.001 F001 250
6827 Hybrid POTT 1P Seal In Delay 0 to 65.535 --- 0.001 F001 0
6828 Hybrid POTT 1P Ground Directional Overcurrent Forward 0 to 4294967295 --- 1 F300 0
682A Hybrid POTT 1P Gnd Directional Overcurrent Reverse 0 to 4294967295 --- 1 F300 0
682C Hybrid POTT 1P Number of Communication Bits 0 to 2 --- 1 F198 0 (1)
682D Hybrid POTT 1P Rx1 0 to 4294967295 --- 1 F300 0
682F Hybrid POTT 1P Rx2 0 to 4294967295 --- 1 F300 0
6831 Hybrid POTT 1P Rx3 0 to 4294967295 --- 1 F300 0
6833 Hybrid POTT 1P Rx4 0 to 4294967295 --- 1 F300 0
6835 Hybrid POTT 1P Target 0 to 2 --- 1 F109 0 (Self-reset)
6836 Hybrid POTT 1P Event 0 to 1 --- 1 F102 0 (Disabled)
68737 Hybrid POTT 1P Echo Condition 0 to 4294967295 --- 1 F300 0
6839 Hybrid POTT 1P Weak Infeed 0 to 2 --- 1 F199 1 (Enabled)
683A Hybrid POTT 1P Weak Infeed Condition 0 to 4294967295 --- 1 F300 0
683C Hybrid POTT 1P Block 0 to 4294967295 --- 1 F300 0
683E Reserved (3 items) 0 to 1 --- 1 F001 0
Pilot Blocking (1P) (Read/Write Setting)
6845 Blocking Scheme 1P Function 0 to 1 --- 1 F102 0 (Disabled)
6846 Block 1P Rx Coord Pickup Delay 0 to 65.535 s 0.001 F001 10
6847 Block 1P Transient Block Pickup Delay 0 to 65.535 s 0.001 F001 30
6848 Block 1P Transient Block Reset Delay 0 to 65.535 s 0.001 F001 90
6849 Blocking Scheme 1P Seal In Delay 0 to 65.535 s 0.001 F001 0
684A Blocking Scheme 1P Gnd Directional Overcurrent Fwd 0 to 4294967295 --- 1 F300 0
684C Blocking Scheme 1P Gnd Directional Overcurrent Rev 0 to 4294967295 --- 1 F300 0
684E Blocking Scheme 1P Number of Communication Bits 0 to 2 --- 1 F198 0 (1)
684F Blocking Scheme 1P Rx1 0 to 4294967295 --- 1 F300 0
6851 Blocking Scheme 1P Rx2 0 to 4294967295 --- 1 F300 0
6853 Blocking Scheme 1P Rx3 0 to 4294967295 --- 1 F300 0
6855 Blocking Scheme 1P Rx4 0 to 4294967295 --- 1 F300 0
6857 Blocking 1P Target 0 to 2 --- 1 F109 0 (Self-reset)
6858 Blocking 1P Event 0 to 1 --- 1 F102 0 (Disabled)
Table B–10: MODBUS MEMORY MAP (Sheet 36 of 77)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
