GE Multilin D60 Line Distance Protection System B-49
APPENDIX B B.4 MEMORY MAPPING
B
7269 Negative Sequence Directional Overcurrent 1 Block 0 to 4294967295 --- 1 F300 0
726B Negative Sequence Directional Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
726C Negative Sequence Directional Overcurrent 1 Offset 0 to 250 ohms 0.01 F001 0
726D Neg Seq Directional Overcurrent 1 Pos Seq Restraint 0 to 0.5 --- 0.001 F001 63
726E Reserved (3 items) 0 to 1 --- 1 F001 0
7271 ...Repeated for Neg Seq Directional Overcurrent 2
Breaker Arcing Current Settings (Read/Write Setting) (6 Modules)
7290 Breaker 1 Arcing Amp Function 0 to 1 --- 1 F102 0 (Disabled)
7291 Breaker 1 Arcing Amp Source 0 to 5 --- 1 F167 0 (SRC 1)
7292 Breaker 1 Arcing Amp Init 0 to 4294967295 --- 1 F300 0
7294 Breaker 1 Arcing Amp Init B 0 to 4294967295 --- 1 F300 0
7296 Breaker 1 Arcing Amp Init C 0 to 4294967295 --- 1 F300 0
7298 Breaker 1 Arcing Amp Delay 0 to 65.535 s 0.001 F001 0
7299 Breaker 1 Arcing Amp Limit 0 to 50000 kA2-cyc 1 F001 1000
729A Breaker 1 Arcing Amp Block 0 to 4294967295 --- 1 F300 0
729C Breaker 1 Arcing Amp Target 0 to 2 --- 1 F109 0 (Self-reset)
729D Breaker 1 Arcing Amp Events 0 to 1 --- 1 F102 0 (Disabled)
729E ...Repeated for Breaker 2 Arcing Amp
72AC ...Repeated for Breaker 3 Arcing Amp
72BA ...Repeated for Breaker 4 Arcing Amp
72C8 ...Repeated for Breaker 5 Arcing Amp
72D6 ...Repeated for Breaker 6 Arcing Amp
Disconnect (Breaker) Switch (Read/Write setting) (24 Modules)
74A0 Disconnect Switch 1 Function 0 to 1 --- 1 F102 0 (Disabled)
74A1 Disconnect Switch 1 Name --- --- --- F206 “SW 1"
74A4 Disconnect Switch 1 Mode 0 to 1 --- 1 F157 0 (3-Pole)
74A5 Disconnect Switch 1 Open 0 to 4294967295 --- 1 F300 0
74A7 Disconnect Switch 1 Block Open 0 to 4294967295 --- 1 F300 0
74A9 Disconnect Switch 1 Close 0 to 4294967295 --- 1 F300 0
74AB Disconnect Switch 1 Block Close 0 to 4294967295 --- 1 F300 0
74AD Disconnect Switch 1 Phase A / Three-pole Closed 0 to 4294967295 --- 1 F300 0
74AF Disconnect Switch 1 Phase A / Three-pole Opened 0 to 4294967295 --- 1 F300 0
74B1 Disconnect Switch 1 Phase B Closed 0 to 4294967295 --- 1 F300 0
74B3 Disconnect Switch 1 Phase B Opened 0 to 4294967295 --- 1 F300 0
74B5 Disconnect Switch 1 Phase C Closed 0 to 4294967295 --- 1 F300 0
74B7 Disconnect Switch 1 Phase C Opened 0 to 4294967295 --- 1 F300 0
74B9 Disconnect Switch 1 Operate Time 0 to 65.535 s 0.001 F001 70
74BA Disconnect Switch 1 Alarm Delay 0 to 65.535 s 0.001 F003 0
74BC Disconnect Switch 1 Events 0 to 1 --- 1 F102 0 (Disabled)
74BD Reserved (2 items) --- --- --- --- ---
74BF ...Repeated for module number 2
74DE ...Repeated for module number 3
74FD ...Repeated for module number 4
741C ...Repeated for module number 5
743B ...Repeated for module number 6
755A ...Repeated for module number 7
7579 ...Repeated for module number 8
7598 ...Repeated for module number 9
75B7 ...Repeated for module number 10
75D6 ...Repeated for module number 11
75F5 ...Repeated for module number 12
7614 ...Repeated for module number 13
7633 ...Repeated for module number 14
7652 ...Repeated for module number 15
Table B–10: MODBUS MEMORY MAP (Sheet 41 of 77)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
