GE Multilin D60 Line Distance Protection System B-83
APPENDIX B B.4 MEMORY MAPPING
B
DC80 Synchrocheck 1 Frequency Hysteresis 0 to 0.1 Hz 0.01 F001 6
DC81 ...Repeated for Synchrocheck 2
DC92 ...Repeated for Synchrocheck 3
DCA3 ...Repeated for Synchrocheck 4
Phasor Measurement Unit Basic Configuration (Read/Write Setting)
DCB4 PMU x Function 0 to 1 --- 1 F102 0 (Disabled)
DCB5 PMU x LDInst --- --- 1 F214 "PMUx \040"
DCD6 PMU x IDcode 1 to 65534 --- 1 F001 1
DCD7 PMU x STN --- --- --- F203 "GE-UR-PMU"
DCDF PMU x Source 0 to 5 --- 1 F167 0 (SRC 1)
DCE0 PMU x Class 0 to 2 --- 1 F549 1 (Class M)
DCE1 PMU x Format 0 to 1 --- 1 F547 0 (Integer)
DCE2 PMU x Style 0 to 1 --- 1 F546 0 (Polar)
DCE3 PMU x Rate 0 to 13 --- 1 F544 4 (10/sec)
DCE4 PMU x PHS-x (14 items) 0 to 14 --- 1 F543 1 (Va)
DCF2 PMU x PHS-x Name (14 items) --- --- --- F203 "GE-UR-PMU-
PHS 1 "
DD62 PMU x A-CH-x (16 items) 0 to 65535 --- 1 F600 0
DD72 PMU x A-CH-x (16 items) --- --- --- F203 "AnalogChannel 1
"
DDF2 PMU x D-CH-x (16 items) 0 to 4294967295 --- 1 F300 0
DE12 PMU x D-CH-x Name (16 items) --- --- --- F203 "Dig Channel 1 "
DE92 PMU x D-CH-x Normal State (16 items) 0 to 1 --- 1 F108 0 (Off)
DEA2 PMU x Reserved (16 items) 0 to 1 --- 1 F001 0
Phasor Measurement Unit Aggregator (Read/Write Setting)
E8A8 PMU Aggregator 1 Name --- --- 1 F209 "MSVID 1 "
E8C9 Aggregator 1 IDcode 1 to 65534 --- 1 F001 1
E8CA Aggregator 1 Protocol 0 to 2 --- 1 F001 0 (NONE)
E8CB Aggregator 1 TCP Port 0 to 65534 --- 1 F001 4712
E8CC Aggregator 1 UDP Port 0 to 65534 --- 1 F001 4713
E8CD PMU Aggregator 1 90-5 UDP Port 0 to 65534 --- 1 F001 102
E8CE PMU Aggregator 1 PDC Network Control 0 to 1 --- 1 F102 0 (Disabled)
E8CF Aggregator 1 Include PMU1 0 to 1 --- 1 F126 0 (No)
E8D0 Aggregator 1 Include PMU2 0 to 1 --- 1 F126 0 (No)
E8D1 Aggregator 1 Include PMU3 0 to 1 --- 1 F126 0 (No)
E8D2 Aggregator 1 Include PMU4 0 to 1 --- 1 F126 0 (No)
E8D3 Aggregator 1 Include PMU5 0 to 1 --- 1 F126 0 (No)
E8D4 Aggregator 1 Include PMU6 0 to 1 --- 1 F126 0 (No)
E8D5 PMU Aggregator 1 ASDUS 1 to 4 --- 1 F001 1
E8D6 PMU Aggregator 1 Port 1 to 3 --- 1 F001 1
E8D7 PMU Aggregator 1 Reserved (3 items) 1 to 3 --- 1 F001 0
Phasor Measurement Unit Aggregator Control Block (Read/Write Setting)
E9C8 PMU Aggregator 1 Control Block SvEna 0 to 4294967295 --- 1 F300 0
E9CA PMU Aggregator 1 Control Block Client Control 0 to 4294967295 --- 1 F300 0
E9CC PMU Aggregator 1 CB SvEna Default 0 to 4294967295 --- 1 F300 0
E9CE PMU Aggregator 1 Control Block ConfRev 1 to 4294967295 --- 1 F003 1
E9D0 PMU Aggregator 1 Control Block Priority 0 to 7 --- 1 F001 4
E9D1 PMU Aggregator 1 Control Block IPClass 0 to 1 --- 1 F563 1 (Expedited
Forwarding)
E9D2 PMU Aggregator 1 Control Block VID 0 to 4095 --- 1 F001 0
E9D3 PMU Aggregator 1 Control Block APPID 0 to 16383 --- 1 F001 0
E9D4 PMU Aggregator 1 Control Block IP Address 0 to 4294967295 --- 1 F003 0
E9D6 PMU Aggregator 1 Control Block Security 0 to 2 --- 1 F001 0
Phasor Measurement Unit Recording Command (Read/Write Command)
EA22 PMU 1 Recording Clear Command 0 to 1 --- 1 F126 0 (No)
Table B–10: MODBUS MEMORY MAP (Sheet 75 of 77)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
