modifications reserved 20 User manual GT Series 6 - 10 kVA UPS 1.0 (GB)
4.5 BATTERY MANAGEMENT
Maximum battery life and reliability are obtained by the following features:
• Battery connection test
At start-up and every minute the unit performs an automatic test to check that the battery cabling and
fuses are properly connected.
If the test detects a battery disconnection, the corresponding alarm will be generated (see section 4.4.7).
• Quick battery test
A quick battery test may be launched to check whether batteries are healthy. To start the test, press
‘UPS on’ button (see section 4.1) for 0.5 seconds when the unit is in “normal operation” conditions (see
section 4.3.1).
In case of failure the corresponding alarm will be generated (see section 4.4.6 / 4.4.7)
• Deep battery test
A deep battery test will update the runtime calculation and may be started via the UPS monitoring
software. The test will start only if the battery charge level is higher than 90% and the load must be at
least 20% of the nominal rating. The runtime calculation will be updated only if the test can run
uninterrupted till complete battery discharge.
NOTE
When executing a deep battery test the available runtime in case of mains failure may be
shorter than normal. Don’t execute this test if reduced battery runtime is not acceptable.
NOTE
It’s possible to reset the battery test, by pressing the ‘UPS off’ switch (see 4.1) for 0.5 sec.
The UPS will switch to bypass mode.
