Chapter 1: Calibration
DigitalFlow™ Multipurpose Ultrasonic Liquid Flowmeter Service Manual 13
CAL
NOTE: Plain text represents prompt area messages and
boxed text represents option bar choices.
Fx represent function keys to select option bar choices.
F1 F2
AB
F1
aLOW
F2
aHIGH
F3
4 mA
Cal
F4
SLOT3
F3
SLOT2
F2
SLOT1
F1
SLOT0
Slot x
(Option Card)
F3
SLOT6
F2
SLOT5
F1
SLOT4
F4
20 mA
F1
EXIT
F1
STORE
F2
ABORT
F3
STORE
F4
ABORT
CALIBRATING
HIGH REFERENCE
HIGH REF
LOW REFERENCE
LOW REF
ANALOG INPUT
Slot x Inputs
(Analog Inputs)
F1 F2
AB
F1
4 mA
F2
20 mA
F3
TEST
F4
EXIT
F1
UP
F2
DOWN
F3
STORE
F4
ABORT
% Full Scale
CALIBRATING
ANALOG OUTPUT
Slot 0 Outputs
(TB I/O)
F1 F2
AB
F1
4 mA
F2
20 mA
F3
TEST
F4
EXIT
F1
UP
F2
DOWN
F3
STORE
F4
ABORT
% Full Scale
CALIBRATING
ANALOG OUTPUT
Slot x Outputs
(Analog Outputs)
F3 F4
CD
F1 F2
AB
F1
aLOW
F2
aHIGH
F1
EXIT
F1
STORE
F2
ABORT
HIGH REFERENCE
HIGH REF
LOW REFERENCE
LOW REF
ANALOG INPUT
Slot x Inputs
(RTD Inputs)
F1 F2
AB
F1
CLOSE
F2
OPEN
F3
EXIT
ALARMS
Slot x Outputs
(Alarms)
F3
C
F1 F2
AB
FREQUENCY
Slot x Outputs
(Freq./Total.)
F3
C
F4
D
PULSES
Figure 6: Calibration Menu Map
