MAINTENANCE/CLEANING
PHOTOELECTRIC CONTR
OL
FINAL ASSEMBLY
STORAGE
6
4
5
7
• To maintain light output, occasional cleaning of the
outer lens may be needed.
• Use a mild, nonabrasive soap or detergent, of neutral
pH (pH approximately 6 to 8), containing no chlorinated
or aromatic hydrocarbons.
• Wash thoroughly, using a soft cloth.
• Rinse with clean, cold water and wipe dry.
• Orient the photoelectric (PE) receptacle so that the
word “North” is directed toward true north.
• Seat and lock a PE control in the receptacle. Lift PE
control/receptacle and rotate clockwise until word
“North” is directed toward true north.
• Lower the PE control/receptacle to seat in position.
• Alternatively, orient the PE receptacle alone. Lift up
on PE receptacle rim and rotate clockwise until word
“North” is directed toward true north.
• Lower the PE receptacle to seat in position. Install PE
control.
NOTE: Door interlocks with top housing in all positions
except in the vicinity of removal location.
NOTE: Doors are designed to be assembled to top
housing while in upright position with gravity holding
hinge pin properly in the hinge cradle.
• Replace door. Hold slightly past vertical and toward
pole-side of hinge.
• Insert hinge pin into hinge cradle and lower door to
hang free.
• Packaged units should NOT be stored unprotected
outdoors in corrugated (cardboard) boxes.
• Store packaged units in a covered dry area not
exceeding -40°C (-40°F) to 50°C (122°F) such as a
roofed area or covered with a secured tarp to keep
water off the corrugated (cardboard) packaging.
0 VDC (-) Gray Lead
Up to 10 VDC (+) Violet Lead
TABLE 2. Wired Dimming Control Connections
